Danfoss iC7 Series Design Manual page 201

Design Guide | iC7 Series Liquid-cooled System Modules
Table 72: Power Loss for INU Modules with Option +AEU1, Motor Cable Maximum Length 50 m (164 ft) (continued)
Model code
iC7-60SLIN07-365AE00F_
iC7-60SLIN07-416AE00F_
iC7-60SLIN07-465AE00F_
iC7-60SLIN07-525AE00F_
iC7-60SLIN07-590AE00F_
iC7-60SLIN07-650AE00F_
iC7-60SLIN07-730AE00F_
iC7-60SLIN07-820AE00F_
iC7-60SLIN07-945AE00F_
iC7-60SLIN07-1060E00F_
iC7-60SLIN07-1230E00F_
iC7-60SLIN07-1400E00F_
iC7-60SLIN07-1500E00F_
iC7-60SLIN07-1640E00F_
iC7-60SLIN07-1795E00F_
iC7-60SLIN07-2080E00F_
iC7-60SLIN07-2300E00F_
iC7-60SLIN07-2500E00F_
iC7-60SLIN07-2830E00F_
iC7-60SLIN07-3050E00F_
iC7-60SLIN07-3260E00F_
iC7-60SLIN07-3500E00F_
iC7-60SLIN07-4035E00F_
iC7-60SLIN07-4400E00F_
iC7-60SLIN07-4850E00F_
iC7-60SLIN07-5300E00F_
iC7-60SLIN07-5600E00F_
Danfoss Drives Oy © 2024.03
Frame Rated
current
I [A]
L(1/5)
IR10L 365
IR10L 416
IR12L 465
IR12L 525
IR12L 590
IR12L 650
IR12L 730
IR12L 820
2xIR12L 945
2xIR12L 1060
2xIR12L 1230
2xIR12L 1400
2xIR12L 1500
2xIR12L 1640
3xIR12L 1795
3xIR12L 2080
3xIR12L 2300
3xIR12L 2500
4xIR12L 2830
4xIR12L 3050
4xIR12L 3260
5xIR12L 3500
5xIR12L 4035
6xIR12L 4400
6xIR12L 4850
7xIR12L 5300
7xIR12L 5600
System module System module
and +AEU1, 2 and +AEU1, 3
kHz switching kHz switching
(1)
frequency frequency
Power Power Power
loss to loss to loss to
liquid air [kW] liquid
[kW] [kW]
4.17 0.15 4.75
4.82 0.18 5.56
4.64 0.15 5.69
5.19 0.17 6.31
5.92 0.19 7.05
6.50 0.20 7.77
7.75 0.24 9.00
8.99 0.28 10.46
9.84 0.31 11.53
10.42 0.34 12.75
12.23 0.39 14.69
14.15 0.44 16.81
15.93 0.51 18.92
17.72 0.56 20.92
17.83 0.58 22.01
21.39 0.68 25.55
24.43 0.78 29.05
27.12 0.86 31.99
29.14 0.92 34.79
32.53 1.03 38.52
35.34 1.11 41.53
36.06 1.14 43.00
43.38 1.37 51.31
46.57 1.45 54.27
52.10 1.65 61.73
55.86 1.78 66.85
60.56 1.91 71.13
(2)
+AKFX
(1)
Power Power
loss to loss to
air [kW] air [kW]
0.17 0.04
0.20 0.05
0.19 0.03
0.20 0.04
0.22 0.06
0.24 0.07
0.28 0.08
0.33 0.11
0.38 0.05
0.41 0.08
0.46 0.11
0.52 0.13
0.60 0.16
0.65 0.19
0.70 0.18
0.80 0.20
0.91 0.23
0.99 0.31
1.08 0.26
1.21 0.31
1.29 0.48
1.34 0.33
1.60 0.51
1.69 0.54
1.92 0.58
2.09 0.59
2.22 0.67
AJ475942178716en-000101 / 172K2848A |
Standby
loss
[kW]
0.07
0.07
0.13
0.13
0.13
0.13
0.13
0.13
0.26
0.26
0.26
0.26
0.26
0.26
0.39
0.39
0.39
0.39
0.52
0.52
0.52
0.66
0.66
0.79
0.79
0.92
0.92
