Danfoss iC7 Series Design Manual page 190

Design Guide | iC7 Series Liquid-cooled System Modules
Table 63: Current Ratings for Inverter Module 525–690 V AC (640–1100 V DC) (continued)
Model code
iC7-60SLIN07-5300E00F4
iC7-60SLIN07-5600E00F4
iC7-60SLIN07-6100E00F4
iC7-60SLIN07-6400E00F4
1) efficiency = 98.5%
Current Ratings for INU 380–500 V AC (465–800 V DC), IP00/Open Type
10.6.7
Table 64: Current Ratings for Inverter Module, 380–500 V AC (465–800 V DC)
(1)
Model code
iC7-60SLINB5-206AE00F4
iC7-60SLINB5-245AE00F4
iC7-60SLINB5-302AE00F4
iC7-60SLINB5-385AE00F4
iC7-60SLINB5-416AE00F4
iC7-60SLINB5-525AE00F4
iC7-60SLINB5-590AE00F4
iC7-60SLINB5-650AE00F4
iC7-60SLINB5-730AE00F4
iC7-60SLINB5-820AE00F4
iC7-60SLINB5-1060E00F4
iC7-60SLINB5-1230E00F4
iC7-60SLINB5-1400E00F4
iC7-60SLINB5-1500E00F4
iC7-60SLINB5-1640E00F4
iC7-60SLINB5-1795E00F4
iC7-60SLINB5-2080E00F4
iC7-60SLINB5-2300E00F4
iC7-60SLINB5-2500E00F4
190
| Danfoss Drives Oy © 2024.03
AC current
I [A] I [A] I [A]
N L H
5411 5300 3975
5717 5600 4200
6227 6100 4575
6534 6400 4800
AC current
I [A] I [A] I [A]
N L H
211 206 155
251 245 184
309 302 227
394 385 289
425 416 312
536 525 393
603 590 442
672 650 487
746 730 547
838 820 615
1083 1060 795
1256 1230 922
1430 1400 1050
1532 1500 1125
1675 1640 1230
1833 1795 1346
2124 2080 1560
2348 2300 1725
2552 2500 1875
Motor output power,
(1)
690 V AC
I [A] P [kW] P [kW]
peak L H
7950 5000 3700
8400 5300 4000
9150 5700 4300
9600 6000 4600
Motor output power,
(2)
500 V AC
I [A] P [kW] P [kW]
peak L H
310 132 90
368 160 110
454 200 132
578 250 160
624 270 200
786 355 250
884 400 250
974 400 315
1094 500 355
1230 560 400
1590 630 500
1844 800 630
2100 900 710
2250 1000 710
2460 1100 800
2692 1200 900
3120 1400 1000
3450 1500 1100
3750 1700 1200
Frame Frame
with
option
+AExx
7 x IM12L 7 x IR12L
7 x IM12L 7 x IR12L
8 x IM12L 8 x IR12L
8 x IM12L 8 x IR12L
Frame Frame
with
option
+AExx
IM10L IR10L
IM10L IR10L
IM10L IR10L
IM10L IR10L
IM10L IR10L
IM12L IR12L
IM12L IR12L
IM12L IR12L
IM12L IR12L
IM12L IR12L
2 x IM12L 2 x IR12L
2 x IM12L 2 x IR12L
2 x IM12L 2 x IR12L
2 x IM12L 2 x IR12L
2 x IM12L 2 x IR12L
3 x IM12L 3 x IR12L
3 x IM12L 3 x IR12L
3 x IM12L 3 x IR12L
3 x IM12L 3 x IR12L
