Design Guide | iC7 Series Liquid-cooled System Modules
Table 64: Current Ratings for Inverter Module, 380–500 V AC (465–800 V DC) (continued)
(1)
Model code
iC7-60SLINB5-2830E00F4
iC7-60SLINB5-3050E00F4
iC7-60SLINB5-3260E00F4
1) The hardware has improved transient withstand.
2) efficiency = 98.5%
Current Ratings for DC/DC Converter 640–1100 V DC-bus Voltage, IP00/Open Type
10.6.8
Table 65: Current Ratings for DC/DC Converter 640–1100 V DC-bus Voltage, IP00/Open Type
Model code
iC7-60SLDC07-300AE00F4
iC7-60SLDC07-360AE00F4
iC7-60SLDC07-420AE00F4
iC7-60SLDC07-480AE00F4
iC7-60SLDC07-570AE00F4
iC7-60SLDC07-720AE00F4
iC7-60SLDC07-840AE00F4
iC7-60SLDC07-960AE00F4
iC7-60SLDC07-1080E00F4
iC7-60SLDC07-1200E00F4
iC7-60SLDC07-1440E00F4
iC7-60SLDC07-1680E00F4
iC7-60SLDC07-1920E00F4
iC7-60SLDC07-2160E00F4
iC7-60SLDC07-2400E00F4
iC7-60SLDC07-2880E00F4
iC7-60SLDC07-3240E00F4
iC7-60SLDC07-3600E00F4
1) Sum of 3 phases.
Danfoss Drives Oy © 2024.03
AC current
I [A] I [A] I [A]
N L H
2889 2830 2122
3114 3050 2287
3328 3260 2445
DC bus
DC source current
current
I [A] I [A] I [A]
N-DC N L
307 307 300
368 368 360
429 429 420
490 490 480
582 582 570
735 735 720
858 858 840
980 980 960
1103 1103 1080
1225 1225 1200
1470 1470 1440
1715 1715 1680
1960 1960 1920
2205 2205 2160
2450 2450 2400
2940 2940 2880
3308 3308 3240
3675 3675 3600
Motor output power,
(2)
500 V AC
I [A] P [kW]
peak L
4244 2600
4574 2800
4890 3000
DC power, 1000...250 V DC
(1)
source
I [A] P [kW]
H L-typ
225 300...75
270 360...90
315 420...105
360 480...120
428 570...142
540 720...180
630 840...210
720 960...240
810 1080...270
900 1200...300
1080 1440...360
1260 1680...420
1440 1920...480
1620 2160...540
1800 2400...600
2160 2880...720
2430 3240...810
2700 3600...900
Frame
P [kW]
H
1950 4 x IM12L
2000 4 x IM12L
2200 4 x IM12L
Frame
DM10L
DM10L
DM10L
DM10L
DM10L
DM12L
DM12L
DM12L
DM12L
DM12L
2xDM12L
2xDM12L
2xDM12L
2xDM12L
2xDM12L
3xDM12L
3xDM12L
3xDM12L
AJ475942178716en-000101 / 172K2848A |
Frame
with
option
+AExx
4 x IR12L
4 x IR12L
4 x IR12L
Frame
with
option
+AE__
DR10L
DR10L
DR10L
DR10L
DR10L
DR12L
DR12L
DR12L
DR12L
DR12L
2xDR12L
2xDR12L
2xDR12L
2xDR12L
2xDR12L
3xDR12L
3xDR12L
3xDR12L
