Figure 97: The Control Board
A
Status indicators (FAULT, WARN, READY)
1
Control panel connector (X9)
3
24 V DC supply (X62)
5
RTC battery holder
7
Ethernet port (X1)

Definitions of the Indicator Lights on the Control Board

8.3
Table 21: Definitions of the Indicator Lights on the Control Board
Indicator name Function (color)
Fault On (red)
Warn On (yellow)
Ready On (white)
Blinking 1 Hz (white)
Fault+Warn+Ready Blinking (red + yellow + white)
X0 link activity Off
On (green)
Blinking (green)
X0 link speed Off
On (orange)
For the description of the fieldbus indicators (ST, X1, X2), see the relevant application guide.
Danfoss Drives Oy © 2024.03
B
3 4 5
6
7
8
B
Fieldbus indicators (ST, X1, X2) and Ethernet port
indicators (X0)
2
Fiber optic link to power unit (X80)
4
microSD card
6
Ethernet port (X0)
8
Ethernet port (X2)
Description
Fault active
Warning active
Ready for operation
Power on, not ready
Winking from an external application. Can be used for identifying where the
external application is wirelessly connected to.
No link
Link OK, no data
Link OK, data communication
No link or 10 Mbps link
100 Mbps link
