Design Guide | iC7 Series Liquid-cooled System Modules
1
Figure 55: Example of Air Circulation Inside an Enclosure
1
Air deflector
3
Air block between wall and system module
64
| Danfoss Drives Oy © 2024.03
1
2
2
3
4
4
2
Critical area (DC fuses and busbars)
4
Critical area (fuses, terminals, busbars, power cables, and
electrical components)
AJ475942178716en-000101 / 172K2848A
