Danfoss iC7 Series Design Manual page 197

Design Guide | iC7 Series Liquid-cooled System Modules
Table 69: Power Loss for AFE and GC Modules (continued)
Model code
iC7-60SL3AB5-1040
iC7-60SL3AB5-1230
iC7-60SL3AB5-1325
iC7-60SL3AB5-1500
iC7-60SL3AB5-1700
iC7-60SL3AB5-1800
iC7-60SL3AB5-2000
iC7-60SL3AB5-2250
iC7-60SL3AB5-2500
iC7-60SL3AB5-2650
iC7-60SL3AB5-2940
1) DC fuses
Power Losses of AFE and GC Modules, Voltage Class B5, with +AEZ1 and +AEZ3
10.7.5
The specifications for the values in the table
l
AFE or GC module
¢
380–500 V AC (465–800 V DC)
¢
DC voltage 594 V DC
¢
Modulator type 4
¢
The default modulator type for grid converters is type 5, which results in slightly lower losses than given in the table.
n
Option +AEZ1 or +AEZ3
¢
Table 70: Power Loss for AFE and GC Modules with Options +AEZ1 and +AEZ3
Model code
iC7-60SL3AB5-261A
iC7-60SL3AB5-325A
iC7-60SL3AB5-380A
iC7-60SL3AB5-425A
Danfoss Drives Oy © 2024.03
Frame
2xAM12L
2xAM12L
2xAM12L
2xAM12L
3xAM12L
3xAM12L
3xAM12L
3xAM12L
4xAM12L
4xAM12L
4xAM12L
Frame Rated
current
I [A]
L(1/5)
AR10L 261
AR10L 325
AR10L 380
AR12L 425
Rated System module
current
Power loss
I [A]
L(1/5)
to liquid
[kW]
1040 9.97
1230 12.23
1325 13.44
1500 15.80
1700 16.58
1800 17.79
2000 20.31
2250 23.70
2500 24.95
2650 26.87
2940 30.76
System module and System module and
(1)
+AEZ1 +AEZ3
Power Power Power
loss to loss to loss to
liquid air [kW] liquid
[kW] [kW]
3.12 0.20 3.26
4.22 0.25 4.43
5.33 0.32 5.62
4.47 0.19 4.58
(1)
+AKFX
Power loss Power loss
to air [kW] to air [kW]
0.10 0.04
0.12 0.07
0.14 0.1
0.16 0.13
0.17 0.11
0.18 0.09
0.21 0.14
0.24 0.2
0.25 0.17
0.27 0.19
0.31 0.28
+AKFX
(2) (3)
Power Power
loss to loss to
air [kW] air [kW]
0.29 0.02
0.38 0.02
0.51 0.03
0.26 0.01
AJ475942178716en-000101 / 172K2848A |
Standby
loss [kW]
0.14
0.14
0.14
0.14
0.22
0.22
0.22
0.22
0.29
0.29
0.29
Standby
loss,
system
module
and
+AEZ1
[kW]
0.04
0.04
0.04
0.07
197
