Danfoss iC7 Series Design Manual page 152

Design Guide | iC7 Series Liquid-cooled System Modules
Dimensions of the Pre-charging Unit, UL
10.2.26
30 60
(1.18) (2.36)
15
(0.59)
112
(4.41)
240
(9.45)
115
(4.53)
156
(6.14)
Figure 153: Dimensions of the Pre-charging Unit in mm (in), UL
152
| Danfoss Drives Oy © 2024.03
292
(11.5)
240
(9.45)
60
Ø6
(2.36)
(0.24)
239
(9.41)
263
(10.35)
AJ475942178716en-000101 / 172K2848A
