Volume Of The Pipe - Danfoss iC7 Series Design Manual

Design Guide | iC7 Series Liquid-cooled System Modules
Table 10: Examples of Measured Coolant Flow Rates of IR12L
Channel 1 flow rate (l/min)
11.6
14.7
17.4
18.2
Table 11: Examples of Measured Coolant Flow Rates of AR12L
Channel 1 flow rate (l/min)
12.8
16.4
19.3
20.2

Volume of the Pipe

6.4.4
0.6
0.5
0.4
0.3
0.2
0.1
0
0 0.2
A
8 mm
C
12 mm
E
16 mm
G
25 mm
Figure 24: Volume of the Pipe with Different Inside Diameters, 8–25 mm
Danfoss Drives Oy © 2024.03
Channel 2 flow rate (l/min)
25.2
32.4
38.3
40.2
Channel 2 flow rate (l/min)
21
26.8
31.7
33.1
0.4 0.6 0.8
[m]
Total flow rate (l/min)
36.8
47.1
55.7
58.4
Total flow rate (l/min)
33.8
43.2
51
53.3
G
F
E
D
C
B
A
1
B
10 mm
D
13 mm
F
19 mm
AJ475942178716en-000101 / 172K2848A |
