Technical data

POWER
Power input TN-S: 230/400 V AC
50Hz
IT: 230 V AC 50Hz
Max 64 A (depends on
model)
Power output AC
Connected to AC supply Yes
network
Permanently connected Yes
to the mains
Charging current Up to 32 A (depends on
model)
Supply Connection TN-S: L1,L2,L3,N,PE
IT: L1,L2,PE
Fuses C-Characteristics.
Breaking capacity 6kA
Mode 3: 32A
Shutter: 20/40A
Standby-usage 18-20 W
consumption
Rated frequency, f 50 Hz
n
Rated diversity factor, 1
RDF
Rated insulation 250/400 V
voltage, U
i
Rated impulse 4 kV
withstand voltage, U
imp
Rated peak withstand 6 kA
current, I
pk
Rated short-time 6 kA
withstand current, I
cw
Max prospective short- 6 kA
circuit current, I
cp
Overvoltage category III
Technical data for RCD
Rated making and 200 A
breaking capacity, I
m
MECHANICS
Weight Up to 24 kg (depends on
model)
Dimension 449 x 282 x 160 mm
H x W x D
10
MECHANICS
Material Front and back cover
in ABS plastic. Colored
zinc oxide metal box for
electronics.
Ingress Protection IP54
Ambient operation -30°C to +50°C
temperature
Altitude < 2000 m
Relative humidity Up to 100 % at +25°C
Storage temperature -30°C to +50°C
External mechanical IK10
impact
INTERFACES
EV connector One or two Type 2 outlets or
Type 2 fixed cable
Display LED symbols
Enclosure lock Mechanical lock with key.
Energy meter Internal or MID-approved
depending on option.
RFID tag Milfare 1k, Milfare 1k+, Milfare
standard Classic. 13,5 MHz.
Connectivity 4G: Frequency band: LTE Cat-1,
B3 B8 B20 power class: 23 dBm.
Fallback GSM/GPRS/EDGE
900 MHz (Max: 2W) 1800 MHz
(Max: 1W).
RF Exposure Users recommended to remain
20cm away from the device
during operation.
COMPATIBILITY
Compliance IEC 61851-1, IEC 62196-
2, IEC 61439-7, CE
Approval Download the
Declaration of
Conformity from
www.ctek.com
Charging method Mode 3
Electric shock Class I equipment
protection
Communication OCPP 1.5 and 1.6
protocol
Pollution degree 3
Intended for use in EMC B
Environment
User & installation instructions
SAFETY
Ground fault detection

OVERCURRENT AND SHORT-CIRCUIT PROTECTION

Rated current, I
n
Characteristic
Rated short-circuit capacity, I
cn
Rated service short-circuit breaking capacity, I
cs
Let-through energy, I t
2
CONFORMITY
Hereby, CTEK AB declares that the radio equipment type, CHARGESTORM CONNECTED 2, is in compliance with
Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following Internet address:
https://www.ctek.com/uk/quality/doc

Part specific data

ART.NO RATED RATED
VOLTAGE, U CURRENT, I
n n
910-17049 230 V 16 A
910-17062 230 V 32 A
910-17050 230/400 V 16 A
910-17028 230/400 V 32 A
40-540 230 V 16 A
40-538 230 V 32 A
40-536 230/400 V 16 A
40-534 230/400 V 32 A
910-17045 230 V 16 A
910-17046 230 V 32 A
910-17047 230/400 V 16 A
910-17048 230/400 V 32 A
910-17042 230/400 V 32/16 A**
910-17051 230/400 V 32/16 A**
910-17063* 230/400 V 64/32 A**
910-17059 230/400 V 32 A
910-17060* 230/400 V 64 A
40-539 230 V 32/16 A**
40-537* 230 V 64/32 A**
40-535 230/400 V 32 A
40-533* 230/400 V 64 A
Built-in RCD Type A (IEC 60947-2), AC 30 mA, DC 6 mA
See Part specific data
C
6 kA
7.5 kA
36000 A s
2
LEFT OUTLET RIGHT OUTLET
- Outlet, 1 ph, 230 V, 16 A
- Outlet, 1 ph, 230 V, 32 A
- Outlet, 3 ph, 230/400 V, 16 A
- Outlet, 3 ph, 230/400 V, 32 A
- Shutter, 1 ph, 230 V, 16 A
- Shutter, 1 ph, 230 V, 32 A
- Shutter, 3 ph, 230/400 V, 16 A
- Shutter, 3 ph, 230/400 V, 32 A
- Cable, 1 ph, 230 V, 16 A
- Cable, 1 ph, 230 V, 32 A
- Cable, 3 ph, 230/400 V, 16 A
- Cable, 3 ph, 230/400 V, 32 A
Cable, 1 ph, 230 V, 16 A Outlet, 1 ph, 230 V, 16 A
Outlet, 1 ph, 230 V, 16 A Outlet, 1 ph, 230 V, 16 A
Outlet, 1 ph, 230 V, 32 A Outlet, 1 ph, 230 V, 32 A
Outlet, 3 ph, 230/400 V, 16 A Outlet, 3 ph, 230/400 V, 16 A
Outlet, 3 ph, 230/400 V, 32 A Outlet, 3 ph, 230/400 V, 32 A
Shutter, 1 ph, 230 V, 16 A Shutter, 1 ph, 230 V, 16 A
Shutter, 1 ph, 230 V, 32 A Shutter, 1 ph, 230 V, 32 A
Shutter, 3 ph, 230/400 V, 16 A Shutter, 3 ph, 230/400 V, 16 A
Shutter, 3 ph, 230/400 V, 32 A Shutter, 3 ph, 230/400 V, 32 A
