CTEK CHARGESTORM CONNECTED 2 User Manual page 163

TN & TT-
systems
Line-
SUPPLY
to-line
INPUT
400V~
X1
L1
2016-1301
X2
L2
2016-1301
X3
L3
2016-1301
X4
N
2016-1304
X5
PE
2016-1307
CTEK AB
3-PHASE CIRCUIT BREAKER AND ENERGY METER CH1
2U
2L
4U
4L
W1 BN 6
6U
W2 BN 6
6L
Curve C value according to BOM
To PSU
W3 BK 6 W10 BK 1.5
W4 BK 6
To PSU
W5 GY 6
W6 GY 6
W8 BU 6
W19 BU 6 3-PHASE CIRCUIT
BREAKER CH2
2U
2L
4U
4L
6U
6L
Curve C value according to BOM
F1
X15
1U
1
1L
3U
2
3L
5U
3
5L
Distr. N
Rail
N
X8
W14 BU 1.5
J4
X7
W33 BU 6
W15
BU
1.5
F2
X16
1U
1
1L
3U
2
3L
5U
3
5L
Distr.
N
Rail
N
Appendices
EM1B
W11 BK 6
L1 4
W12 BK 6
L2 5
W13 BK 6
L3 6
EM340
Energy Meter
To MRCD
parts CH1
3-PHASE ENERGY
METER CH2
EM2B
W27 BK 6
L1 4
W28 BK 6
L2 5
W29 BK 6
L3 6
EM340
Energy Meter
To MRCD
parts CH2
CH1_L1
CH1_L2
CH1_L3
CH1_N
CH2_L1
CH2_L2
CH2_L3
CH2_N
B
