Bulk Charging Time; Technical Data - CTEK MULTI US 7000 User Manual

Voltage AC
Current
Back Current Drain*
Charging Voltage
Ripple**
Charging Current
Ambient Temperature
Cooling
Charge cycle
Type of batteries
Battery Capacity
Dimensions
Insulation
Weight
*) The back current drain is the current that the charger uses from the battery when the
wall plug is not connected. The reverse current of the MULTI US 7000 is very low and
corresponds to 1 Ah per month.
**)The ripple wave describes how many disturbances are exhibited by current and volt-
age. A rippled voltage can cause damage to other equipment connected to the battery.
The MULTI US 7000 supplies voltage and current with very low voltage rippling. This
increases the life of the battery and ensures that equipment connected to it will not be
damaged.

BULK CHARGING TIME

Battery size
(Ah)
14
50
90
150

TECHNICAL DATA

85-125 VAC, 50-60 Hz. Output power is reduced at lower input
voltage.
2.0 A rms
< 3 mA
Nominal: 12 V, 13.6 V, 14.4 V, 14.7 V or 16 V
Max 150 mV rms, max 0.3 A
7 A max
- 20°C till + 50°C. Automatic reduction of power at increased
ambient temperature.
Natural convection. Do not cover the charger.
5 step fully automatic IIUoIUp.
All types of lead-acid batteries (Wet, Maintenance Free, VRLA,
AGM and most GEL).
14-150 Ah
8 1/2 x 3 1/2 x 1 7/8 inches (L x W x H)
Splashproof/Rainproof.
1.7 lbs
Time to ~80% charge
(h)
2
6-7
11-13
20-22
13
