CTEK CHARGESTORM CONNECTED 2 User Manual page 162

IT- TN & TT-
nett systems
Single Line- Line-
phase to-line to-line
230V~ 230V~ 400V~
Use Use Use
3-way 2-way 2-way
jumper jumper jumper
L1 L1 L1
no no no
connect connect connect
no L3 L3
connect
N L2 N
PE PE PE
A
TN & TT-
systems
Line-
to-line
400V~
SUPPLY
No
INPUT
jumper
X1
L1
W1 BN 6
2016-1301
To PSU
X2
L2
W69 BK 1.5
2016-1301
X3
L3
W6 GY 6
2016-1301
X4
N
W8 BU 6
W75 BU 6
2016-1304
X5
PE
2-way jumper Wago 2016-402
2016-1307
3-way jumper Wago 2016-403
1-PHASE CIRCUIT BREAKER AND ENERGY METER CH1
F1
2U 1U
2L 1L
4U 3U
4L 3L
Curve C value according to BOM
W70 BU 6
X7
J3
X8
To PSU
1-PHASE CIRCUIT BREAKER AND ENERGY METER CH2
F2
2U 1U
2L 1L
4U 3U
4L 3L
Curve C value according to BOM
Appendices
EM1B
W61 BK 6 W71 BK 6
1 L 2
W62 BU 1.5
N N
EM111
Energy Meter
W64 BU 6
W63 BK 1.5
EM2B
W65 BK 6 W73 BK 6
1 L 2
W66 BU 1.5
N N
EM111
Energy Meter
W68 BU 6
W67 BK 1.5
CH1_L1
To MRCD
parts CH1
CH1_N
CH1_FUSE_FB
CH2_L3
To MRCD
parts CH2
CH2_N
CH2_FUSE_FB
CTEK AB
