7.1.7 Setting Other Functions

Setting other functions as follows is possible.
Setting Items
Zone recording）
The data for each channel can be recorded separately in another area so that they will not overlap.
Partial compression/expansion）
Record the measured data of the channel, partially compressed/expanded.
Digital print）
Specify with ON/OFF whether the measured data for each channel is to be printed or not.
Tag）
Set the tag, which is to be printed instead of a channel number, for logging print or manual print.
Setting up to 5 characters (See Page 68 for Character Code Table), as the tag for each channel is
possible.
Comment words）
Set the comment words to be printed by DI. There are three kinds of comment words and setting up
to 12 characters (See Page 67 for Character Code Table) for each channel is possible.
Operation
Setting Mode
Zone Recording
Partial Compression/Expansion
Digital Print
Tag
Comment Words
