7.1.4 Setting the Chart Speed
Setting Items
Set the chart speed. Select it from the table below.
Table 7.2 Chart Speed (Unit: ㎜/h)
5
10
80
90
360
375
2400
3000
12000
Operation
Setting
When setting the 1st chart speed to 1500 ㎜/h
Example)
Display
[Note]
When altering the chart speed with the DI option, set the 2nd chart speed.
If the DI option is not attached, setting of the 2nd chart speed becomes invalid.
Display
15
20
25
100
120
150
450
600
720
3600
4500
4800
1st/2nd Chart speed
Operation Keys
ESC
3 sec
MENU
ENT
PRINT
ENT
PRINT
Operation Keys
FEED
PRINT
ENT
―69―
30
40
160
180
750
900
5400
6000
Chart speed
Description
Press the "MENU" key for 3 seconds or more to
enter the setup mode. Use the △ key to indicate
", and press the "ENT" key.
"
Use the △ key to select the 1st chart speed, and
press the "ENT" key.
Description
Use the △ key to set the 1st chart speed, and press
the "ENT" key.
Press the "ENT" key. To return to the user mode,
hold down the "MENU" key for 3 seconds or more.
50
60
75
200
240
300
1200
1500
1800
7200
9000
10800
HXPRM10mnCT002E
