9.0

TNC-5000 Telephone Network Controller Module

9.1

Module Mounting Locations

The TNC-5000 Telephone Network Controller board can be mounted in one place. The TNC-
5000 Telephone Network Controller Board is mounted above the ANC-6000 Audio Network
board, both are mounted in position 2 above the main fire alarm board, see Figure 51.
9.2

Typical Addressable Telephone Set-up

The typical addressable telephone set-up is with an addressable fire alarm system using the
TNC-5000 and from the TNC-5000 to the Master Telephone (QMT-5302NV). The selector
panels (QAZT-5348DS) are connected to the Master Telephone by cable only. The MIX-
M500FP(A) Control Modules are connected to the addressable loop from the main fire alarm
panel and to each other and the Master Telephone. Remote telephones are connected to the
control modules.

Figure 56 Typical Addressable Telephone Set-up

TM
FleX-Net
FIRE ALARM PANEL
TNC-5000
TELEPHONE
NETWORK
CONTROLLER
MODULE
Addressable Loop
QAZT-5348DS
ADDRESSABLE
TELEPHONE
SELECTOR
QMT-5302N/V
ADDRESSABLE
MASTER
TELEPHONE
TNC-5000 Telephone Network Controller Module
MIX-M500FP(A)
T
CONTROL
MODULE
Remote Telephones
MIX-M500FP(A)
CONTROL T
MODULE
Remote Telephones
MIX-M500FP(A)
CONTROL
T
MODULE
Remote Telephones
MIX-M500FP(A)
T
CONTROL
MODULE
Remote Telephones
T T T
T T T
T T T
T T T
