Table 13: Analog Loop Wiring - Mircom FLeXNet FX-MNS-6000 Installation And Operation Manual

Table 13:
Wire Gauge
(use twisted pair)
(AWG)
12
14
16
18
i
Note:
Power Wiring: Use Table 12: Wiring Table for NACs on the previous page to see the wiring
information for the remote annunciator being used.
RS-485 Wiring: See the wiring information for the remote annunciator being used.
4-Wire Smoke Wiring: The maximum allowable current is 0.2 amperes. The maximum
allowed voltage drop is 1 volt. Refer to Table 12: Wiring Table for NACs on the previous page.
Shield for Analog Loop Wiring: Only twisted pair is recommended, but if shielded twisted
pair is used, wire shield at the start and the end of the loop to the terminals marked Shield at
the loop adder board.
59
Analog Loop Wiring
10,000
7971
4980
3132
Line capacitance shall not exceed 0.5 F.
Inductance shall not exceed 1 mH.
Resistance shall not exceed 40 ohms.
Loop Total (Out and In) Maximum
Twisted Pair Wire Run
ft. m
3049
2429
1518
955
