15.1

FX-MNS-6000 Audio Specifications

i
Note:

Table 18FX-MNS-6000 Audio Specifications

Model QPS-6650 Power Supply and Charger
•
0 to 49 degrees Celsius, 0 to 93 + or - 2% RH (non-
condensing) operating range
•
Power input: 120 VAC, 60Hz / 230 VAC, 50Hz
• Power supply ratings:
Primary input is non-power limited
•
Battery: 24VDC, Gel-Cell/Sealed Lead-Acid
•
• Charging for up to 80 AH batteries
Model ANC-6000 Audio Network Controller Module
Current consumption: standby: 82 mA
•
Model QCC-6000 Communication Card
• Current consumption: standby:
Model QAD-6425-70 (-25) Amplifier with 100 Watts
• 70V or 25V constant voltage output
• One to four, fully supervised Class "A" or "B"
speaker zones
• 100 Watts maximum per amplifier
•
Freq. Response: UL bandwidth from 800 to 2800 Hz
ULC bandwidth from 400 to 4000 Hz
• Harmonic distortion less than 2.5% at 1 KHz
• Current consumption:
25V Model standby: 314mA, alarm: 5.62A
70V Model standby: 270mA, alarm: 5.97A
Model QAZT-5348DS Paging or Telephone Selector
Panel
• Mounts in a BBX-FXMNS-6000 enclosure
• Connects to QMP-6101NV to provide 48 zones of
paging control
• Up to one per QMP-6101NV
• Current Consumption:standby: 10mA
All circuits are power limited, unless specified otherwise.
120 VAC, 6.1A, 732 Watts
230 VAC, 3.13A, 720 Watts
alarm: 87 mA
71.4mA
77mA
alarm:
alarm: 22mA
Model FNC-2000 Fire Network Controller Module
• Current consumption: standby: 190mA
Model TNC-5000 Telephone Network Controller
Module
• Current consumption: standby:
Model FOM-2000-UM Fiber Optics Module
•
Current consumption:
standby: 16mA (single mode) or 42mA (multi-mode)
16mA (single mode) or 42mA (multi-mode)
alarm:
Model QMP-6101NV Paging Microphone
• Mounts in a BBX-FXMNS-6000 enclosure
Current Consumption:standby: 20.5mA
•
Model QMT-5302NV Master Telephone
• Mounts in a BBX-FXMNS-6000 enclosure
• Current Consumption: standby: 1mA
190mA
alarm:
195mA
215mA
alarm:
alarm: 20.5mA
alarm: 13mA
