3.1.1 FX-6000MNS-CH Main Fire Alarm Chassis
This chassis mounts into the BBX-FXMNS-6000 Enclosure (backbox) as shown below.
Figure 5
NOTE: Up to 9 modules
can be mounted over
the main fire alarm board
Slot 2 is reserved for
ANC-6000 and TNC-5000
Slot is reserved for
FNC-2000.
SGM-1004A
4 NAC module
15
FX-6000MNS-CH mounted within the BBX-FXMNS-6000 Enclosure
Inside Backbox View
FX-6000MNS-CH
Main Fire Alarm Board
Chassis
SGM-1004A
4 NAC module
