Figure 72 Evacuation Codes - Mircom FLeXNet FX-MNS-6000 Installation And Operation Manual

13.6.3 Evacuation Codes
Single stage codes
Continuous
Temporal Code
March Code
California Code
Two-stage codes
Alert Code
General Alarm

Figure 72 Evacuation Codes

103
On 100% of the time
3 of 0.5 second on, 0.5 second off then, 1.5 second pause
0.5 second on, 0.5 second off
5 seconds on, 10 seconds off
0.5 second on, 2.5 seconds off
Evacuation code as selected from above.
Continuous
0.5s 1.5s Temporal Code
0.5s
0.5s
March Code
0.5s
10s
California Code
0.5s
Alert Code
2.5s
