Dspl-2440 Graphical Main Display Module; Figure 12 Dspl-2440 Graphical Main Display Module - Mircom FLeXNet FX-MNS-6000 Installation And Operation Manual

4.3

DSPL-2440 Graphical Main Display Module

The DSPL-2440 is a separate item. It can be mounted onto the inner door of the BBX-FXMNS-
6000. It can replace the DSPL-420DS found with the model FX-6000MNS-CH.

Figure 12 DSPL-2440 Graphical Main Display Module

TROUBLE
QUEUE
P1: Cable connects to P14 of the main fire alarm board (Figure 10).
P2: Connection to P1 of any adder display module if used.
i
Note:
23
TROUBLE
SUPV
QUEUE
QUEUE
The main display module comes with slide-in paper labels including both English
and French slide-ins, and laser printer-compatible blanks for zone labelling.
BLDG
QUEUE
