3.0
Installation
This chapter describes the installation of the BBX-FXMNS-6000 enclosure and the BB-6001
enclosure.
3.1
BBX-FXMNS-6000 Enclosure Installation
This enclosure can accommodate the FX-6000MNS-CH chassis with FleX-Net main fire alarm
board and adder modules, the QMP-6101NV vertical mounting master paging microphone and
the QMT-5302NV Master Telephone panels.The BBX-FXMNS-6000 enclosure includes a
backbox, an inner door and an outer door.
Figure 3
45.9"
7.6"
13
BBX-FXMNS-6000 Enclosure
22.4"
20"
44.3"
9"
