Table 17
Total
Power
Watts
25
50
75
100
10.0

Indication

Figure 70 Audio Cabinet Displays and Controls

Card Level LEDs
Amplifier Circuit LEDs
(Four groups of 4 LEDs)
There are 20 LEDs provided on each amplifier. The top group of 4 LEDs are for each terminal
block (Card Level LEDS) and the 16 LEDs below are four groups of 4 LEDs used for the
amplifier circuits.
10.1

Amplifier Displays

FOUR CARD LEVEL LEDS
Power
Internal Trouble
91
Wiring Chart for 25V Speakers
Maximum Wiring Run To Last Device (ELR)
18AWG
ft m ft
218 66 346
109 33 173
73 22 115
54 17 86
16AWG 14AWG
m ft
105 550
53 275
35 183
26 138
Indication
12AWG
m ft m
168 875 267
84 437 133
56 292 89
42 219 67
