  • Page 1 Network Intelligent Fire Alarm and Audio System Table of Contents...

  • Page 2: Table Of Contents

    Table of Contents Configuration ................................7 Overview ................................... 8 GUI - Major Components ........................... 8 Edit Menu ................................. 9 File Menu ................................10 Insert Menu ................................11 Job Menu ................................12 Panel Menu ................................14 Tools Menu ................................15 Add Amplifier ................................ 16 Add Circuit Adder ..............................
  • Page 3 Audio Message Composer ..........................41 Audio Setup ................................45 Backup Database ..............................46 Manage Messages ............................... 48 Select Job to Compare ............................49 Compare Jobs Advanced Options ......................... 50 Create Job ................................51 Display Structure ..............................52 Edit Job ..................................54 Export Job ................................
  • Page 4 Update Panel Time .............................. 83 Version History ..............................83 XML Export / Job Details Options Dialog ....................84 Audio Controller Details ............................ 85 System/Node/CPU Status ..........................87 Correlations ................................90 Interval List View ..............................92 Timer List View ..............................94 Dialer ..................................
  • Page 5 Send Job ................................142 Suite Silence Configuration ........................... 144 Delete Item ................................146 Modify Item ................................ 146 Copy ..................................146 Paste ..................................147 Paste Special ............................... 147 User Preferences ............................... 147 Print ..................................147 Print Preview ............................... 147 Add Loop Controller ............................147 Add Annunciator ...............................
  • Page 6 Panel Info ................................153 Security Key Information ..........................153 Upgrade Firmware ............................153 Extract All ................................153 Build Job ................................153 Build Job ................................154 Link Statistics ..............................154 Display Structure ............................... 154 Custom Messages ............................154 Security Key Information ..........................157 System Status Details ............................

  • Page 7: Configuration

    Configuration The FleX-Net™ system, FleX-Net™ FX-4000 system, and the FX-MNS-6000 network system is configured using MGC software MSW-036. NOTICE TO USERS, INSTALLERS, AUTHORITIES HAVING JURISDICTION, AND OTHER INVOLVED PARTIES This product incorporates field-programmable software. In order for the product to comply with the...

  • Page 8: Overview

    APB-200/COA No sound (no Sounder base correlation), correlation to CO Temporal-3, No Sound (no input Temporal-4, March correlation) Code, Maintenance Chirp, Continuous Tone Overview In order to operate as a fire alarm, a fire alarm panel must be loaded with firmware and configuration data.

  • Page 9: Edit Menu

    Custom Timers or Walk Test Areas. The others are to allow you to view groups of things in the job without having to search through the node, like Input Summary. The top right pane is used to display the details of the currently selected tree branch. This can be a form view or a list view.

  • Page 10: File Menu

    Paste Similar to Paste: Opens the Paste Special dialog to allow defaults to Ctrl++Shift+V Special be changed before pasting. File Menu The File Menu contains the following commands: Name Short cut Description By default the backup database makes a copy of the Master Database in the File folder specified in the User Preferences.

  • Page 11: Insert Menu

    *.MDB files, *.fx2job files and a variety of XML formats. The Job Build folder is the default location for .c files produced by Tools / Build Job. It is also the location of log files which Mircom technical support may request when investigating a problem.

  • Page 12: Job Menu

    Add UDACT Add UDACT capability to the selected network node. Context Dependent Add Device If the selected tree item is a device loop, add a device or circuit. If the selected tree item is the Custom Messages branch of a remote Add Message annunciator, add a Message.
  • Page 13 This command opens a dialog from which you can select any job or job version from an external database or serialized job archive. Import Job The selected job will then be imported and converted to the current job format if necessary. Exports the current job.

  • Page 14: Panel Menu

    Panel Menu The Panel Menu contains the following commands. Name Short Cut Description This command will establish a connection between the configuration tool and the panel, enabling most of the other Connect Ctrl+L commands in this menu. Remember to disconnect when you are finished, as a trouble will be indicated on the fire alarm panel as long as the laptop is connected.

  • Page 15: Tools Menu

    Tools Menu The items under the Tools Menu are used mainly for troubleshooting and diagnostic purposes by the factory. Name Short Cut Description Extracts the latest version of every job to individual database Extract All DB files. Builds the job, assuming the latest product version, creating a Build Job Ctrl+B ".c"...

  • Page 16: Add Amplifier

    Note: The Tools menu is only available if you checked the Show Tools Menu option. See User Preferences Add Amplifier This dialog is displayed in response to an Add Amplifier command, which is available when an Amplifier Loop is selected in the Job Tree. Select the amplifier type.
  • Page 17 Adder Type – Select the type of Circuit Adder to add, from the drop down list of those available on your system. The FleX-Net™ system supports 3 types: 8 Input Adder - 8 Ckts: • Will add additional DM-1008A Input Module with 8 Class B (4 Class A) Input Circuits.

  • Page 18: Add Correlations

    Add Correlations This dialog is displayed in response to the Add Correlations command. The dialog shows a tab for every category of circuit or display item, etc. that can be correlated to the items selected in the top, right pane view of the user interface. The tab categories mirror those of the Correlations View.
  • Page 19 Device: is the major devices list, with choices such as Photo Detector, Ion Detector, Supervised Output Module, etc. Options: Currently only used with AP devices to select what type of base (normal, sounder, etc.) the device is mounted in. Type: is the type of device (e.g. Alarm, Supervisory, etc.) being added. The list of available device types in the combo box is adjusted according to the Device field.

  • Page 20: Add Group

    If at any time during the transaction there are no more available addresses, the entire transaction is rolled back. No devices will have been added. If there are no available addresses for the chosen Type then the Add button is disabled. You can select another type, or close the dialog.

  • Page 21: Add Display Adder

    The Close button dismisses the dialog. Add Display Adder This dialog is displayed in response to an Add Display Adder command, which is accessible when a Main Display or Remote Annunciator is selected in the Job Tree. Select Adder Type - This control lists valid adder types. The list only shows adder types that are allowed for the chosen annunciator.

  • Page 22: Add Loop Controller

    Type - Choose the type of adder you want to add. Different products may list different options. Only the Quad Loop Adder is available in FleX-Net™ jobs. Number to add - Enter the number of loop controllers you want to add. You can have a maximum of 7 Quad Loop Adders per node, 6 if an Audio Controller is used.

  • Page 23: Add Message

    Add Message This dialog is displayed in response to an Add Message command, which is available when Custom Messages is selected under a LCD Annunciator. You can select from Input or Output Type. The Add button is disabled until you type at least one character into the first row of the Message fields.

  • Page 24: Add An Output Group

    From Template – Selecting this radio button adds a standard, blank node. From existing Job – Selecting this radio button opens the job selection window from which you can select any node on any job in the library to use as a pattern for your new node. Click Add to continue.
  • Page 25 5. Click Add. Note: After the operation is completed, the dialog box will remain open for re-use. The address value is adjusted to account for all the devices added. If at any time during the operation there are no more available addresses, the operation will be rolled back and there will be no change.
  • Page 26 Note: If you selected Sounder Base in the Type menu, then you can only add Sounder Base (AP) devices. If you selected Relay Base in the Type menu, then you can only add Relay Base (AP) devices. If you selected Output Module in the Type menu, then you can only add Control (AP), Six Relay Control (AP), and Relay (AP) devices.

  • Page 27: Add Udact

    3. Select the Signal tab for Control (AP) and Sounder Base (AP) devices, and select the Relay tab for Relay (AP) devices. 4. Select the same output devices that you added to the output group when grouping them. To select more than one device, hold down the Ctrl key and click on the devices.

  • Page 28: Add Zone

    Add Zone This dialog is displayed in response to an Add Zone command, which is available when Input Zones is selected in the Job Tree. Device: is the Device Type, currently only Input Zone is available. Options: Currently not used. Type: is the type of zone (Alarm, Supervisory, Trouble, or Monitor) being added.

  • Page 29: Address Scheme

    Address Scheme The configurator currently uses a sophisticated addressing scheme designed to avoid conflicts with virtual devices. The different types of adder are described below: nn a two digit number is the legacy addressing format for a CLIP sensor. • 1nn a two digit number with a 1 in front of it is the legacy addressing scheme •...

  • Page 30: Advanced Panel Information Dialog

    Advanced Panel Information Dialog To access this dialog, select Panel Information from the Panel Menu, and then click on the Advanced button. This dialog polls all the nodes and CPUs on the panel and checks their status against the configuration. This dialog is available from the Panel Information dialog, which is open by a command on the Panel Menu.

  • Page 31: Node Control (Request/Grant/Deny)

    Node Control (Request/Grant/Deny) Functionality overview As per Section 4.16.1 of the ULC standard the Voice Alarm Feature (Paging), the phone system and some manual control switches should only be operated from one location at any given time. In a multi-node setup, this is accomplished by having a display and control centre take over control of the system.
  • Page 32 Configuring a switch for Node Control: User is responsible for selecting which features shall be locked when a node is not in control. This is done by adding the ER flag to the switches for these features - see Loop Detail.
  • Page 33 Requesting control Scenario 1: Idle System Example: The system is Idle and a user on Node 1 wishes to access a function which is restricted by Node Control. The user presses the local Telephone/Page Selector switch that has been correlated with Node 1. Since the system is idle, control is granted automatically. The LEDs correlated with Node 1 control illuminate steadily everywhere on the network and Node 1 has control of the system and access to all functions restricted by Node Control.
  • Page 34 When the system is not idle control has to be explicitly granted to the requesting node by the node currently in control. Sequence of operation: User presses the switch correlated to the node he is at • o Transfer of control is requested o Green LEDs start blinking to indicate that a node is requesting control Note: There is a timer which is started when a node requests control.
  • Page 35 Example: The user at Node 3 has control of the system and is finished using the functions that are restricted by Node Control. The user wishes to automatically grant control to the next user who needs it, so the user presses the local Telephone/Page Selector switch that is correlated with Node 3 (the LED of which is illuminating steadily).
  • Page 36 o Green LEDs of the granted node stop blinking and turn ON solid o Green LEDs of the previously in control node extinguish Example: Node 1 has control, and a user on Node 3 wishes to access a function which is restricted by Node Control.
  • Page 37 Degraded: In a multi-node setup a cluster of nodes can get disconnected from the rest of the system if the communication links are broken. When that happens, the nodes in each group enter degraded mode of operation. Following Figure shows two clusters of nodes that were initially part of the same system.
  • Page 38 granted when requested at that node. Node 2 continues to hold control since it is still connected to nodes 1,3 and 4. Scenario 6: Disconnected node is currently in control 5-Node system • Node 5 is in control • Node 2 gets disconnected - refer to the Figure A group of nodes in degraded •...

  • Page 39: Node Grouping

    LED states meaning: OFF – normal • Solid - degraded • Blinking - standalone • Naturally, the LED will not accurately indicate the condition (for example degraded vs. standalone) of a node that is not in communication with the node the LED is located on. Node Grouping Node grouping is a way of isolating nodes from each other.
  • Page 40 5. Double-click under Fire Panel and select the X to add Fire Panel to the Fire Group. 6. Click Insert - Add Group. 7. Type a name for the second group, for example MNS Group, and then click OK. 8. Double-click under MNS Panel and select X to add MNS Panel to MNS Group. Renaming a group 1.

  • Page 41: Audio Message Composer

    Deleting a group 1. Right-click the group then click Delete Group 2. Click OK. Note: A group can only be deleted if it contains no member nodes. If the group has member nodes, the nodes must first be removed then the group can be deleted. Removing a node from a group 1.
  • Page 42 Audio Message Composer dialog User can define the number of repetitions in the Repeat count edit box (editable only for loops). Repeat forever (Repeat count = 0) should be used with care. If there are following clips, they will never be played. Repeat count value is auto populated in the loop node property upon typing in the edit box.
  • Page 43 will receive another RIFF section, to include some naming and versioning information. Once a WAV file has been imported, it will be listed in the Audio Clips and is available for use in digitized messages. Play When this button is pressed it plays the selected clip. If the type is External, a user’s recorded WAV file is played.
  • Page 44 Commands in the Composition list view can be played using the button. At any time button can be used to stop the Composition playback. Errors / Warnings If User constructed the message composition with loops that do not have clips under them, the error will be issued when User clicks the Play button or the OK button.

  • Page 45: Audio Setup

    Audio Setup This dialog is displayed in response to clicking the Setup button in the Audio section of the Job Details page. Alert and Evac state options – press the ... (ellipsis) button to launch the Manage Message Dialog to select which audio tone or digitized message to broadcast when the system reaches that state.

  • Page 46: Backup Database

    Disable Audio Synchronization – when checked, audio synchronization between nodes is disable. When un-checked audio is synchronized between the nodes. Paging has priority over automatic alarm – when checked, FleX-Net™ system with paging will have priority over alarm: if PTT (PushToTalk) is active during alarm the paging is not disabled.
  • Page 47 After the Backup is complete, if the Keep Only Latest Versions After Backup option of User Preferences is enabled, old versions of each job in your main database will be deleted, retaining only the latest version of each job. The backup can be used by the Restore Database command to recover all of the jobs in the database.

  • Page 48: Manage Messages

    Manage Messages To access this dialog click the Manage Message... button in the Audio Setup dialog. It lists all of the available messages. Some standard messages and tones are built into the firmware and can be chosen for use as Alert or Evac.

  • Page 49: Select Job To Compare

    Compact Database A database that has been the subject of many deletions and additions can become fragmented and occupy more space than required. Compact Database executes a standard MS-Access utility to recover the space and improve performance. Note: This may take several minutes for a large database Select Job to Compare To access this dialog, select Compare Job Versions from the Job Menu.

  • Page 50: Compare Jobs Advanced Options

    Show Identical Items - Check this box if you want to see not only changes, but also those items that stayed the same. Normally you will leave this un-checked. Differences are easier to see and Print generates less output if identical items are not included. Advanced Options - When you press this button the Advanced Options dialog is launched.

  • Page 51: Create Job

    filtering is only applied to the Device, Display Item and similar lists. It is intended to make it easy to see what components have been physically added or removed from the job. Correlations are not considered to be items in this context. If a correlation was added, then that is effectively a modification to the item that received the correlation.

  • Page 52: Display Structure

    Copy current job data As an alternative to choosing a standard template, check • this box to make a copy of the current job (which is presently open in the configurator). In this case the Panel Model and Job Template controls are disabled.
  • Page 53 Choose the Node and CPU. • Choose the Structure on that CPU. Loop structures are qualified with a loop • number. e.g. gLCUPollData - Loop 2. Choose the entry (for Poll Data there is one entry per device, other structures •...

  • Page 54: Edit Job

    To log to file check the Log To File box and specify a destination file. • You can adjust the refresh rate, the start entry and the number of entries while the display is running. They will take effect after the next interval has expired. To view a different structure you must first press stop.

  • Page 55: Export Job

    If job has only one network node and the user attempts to toggle the lock from on to off, then the following message appears. (If an attempt is made to edit the same job on one of its lists or forms, a similar dialog is shown but without the option to unlock the job.) If you choose to proceed, the job is unlocked.
  • Page 56 Export can be used to exchange a single job, for example between technicians. The fx2job format results in a very small file, suitable for electronic transmission. These and other formats are described below. Database Files (*.mdb) - A Microsoft Access database containing a single job is •...

  • Page 57: Firmware Archive Contents

    Shortcuts Keys: Ctrl-E Firmware Archive Contents To access this dialog, click the View Archive button on the Upgrade Firmware dialog. It lists all of the files in the archive. Type Either Firmware (the firmware image) of Dnld Program (a small boot strap program sent by Upgrade Firmware).

  • Page 58: Holidays

    HW Vers The compatible hardware version. About Dialog Displays the copyright notice and version number of your copy of the Configuration Utility. Holidays This dialog allows you to add and remove holiday definitions for use when a panel is configured with the After Hours option. To access this dialog you must first ensure that the Enable Auto After Hours checkbox on Job Details is filled.

  • Page 59: Import Job

    e.g. 9999 99 01 to specify that the first of every month is a holiday. • e.g. 9999 07 99 to specify that the site is shut down for the whole of July for • summer vacations. By default the holiday has a Duration of 1 day. Change this to specify a longer holiday. e.g.

  • Page 60: Logic Editor Dialog

    location of the file to read. The location defaults to the Job File folder specified in User Preferences If the selected type is MDB, then the Microsoft Access database (usually a database that resulted from a Backup Database) is opened. A list view, similar to the Open Job dialog, displays jobs contained in the database.
  • Page 61 Using this dialog the user can compose an equation to be applied to a local, dummy input zone. The input zone is then correlated, using regular IO corrs, to the output which is ultimately the object of the equation. This is done by specifying any number of local and remote inputs zones, local input circuits, timers and intervals (operands) and boolean expressions (operators).
  • Page 62 01-00-L2-SM-005 , 01-00-L2-SM-006 , 01-00-L2-SM-007 , 01-00-L2-SM-008 , 01-00-L2-SM- 009 , 01-00-L2-SM-010 , 01-00-L2-SM-011 ) Associate an equation with a dummy input and then reference that input in several equations attached to outputs. In this example zone 3 will be TRUE if smoke detectors 5, 6 and 7 are active.
  • Page 63 The equation 01-00-02-IN-001:A is true only when this input device is in alarm. • If you do not apply a Device Status to an input, any change in the input's status results in the equation becoming true. For example, the equation 01-00-02-IN-002 (a single input device with no Device Status) is true whenever this input device changes status.
  • Page 64 The remaining columns are the Node, Type and Tag of the input. It is highly recommended that Tags be assigned to all zones and devices intended for use in Advanced Logic for clarity sake. The circuit, timer or switch can be simply tested for TRUE and FALSE, or a particular Device Status can be tested.
  • Page 65 Sys Def The Sys Def button inserts a named constant into the equation. You can select a named System Def in the drop down list before pressing the button. Note: named constants HOA_ON and HOA_OFF from the drop down list shall be used only for HOA Switches.
  • Page 66 Max number of characters within all equation comments - 65536 characters per • CPU; Max number of equations within input zones - 880 equations per CPU; • Max size of single equation - 4096 characters. •...
  • Page 67 Manage Jobs This dialog appears in response to the Manage Jobs command (Panel Menu). The configurator detects the Nodes and CPUs actually present and on-line. It then reads the panel's file system directory from each CPU. The result is displayed in tree form. Normally, for any given job there will be a file on every CPU.
  • Page 68 inactive Job. The Active Job in the panel is shown in Orange color. You can also delete an inactive job by highlighting it and clicking the Delete button at the bottom of the dialog or pressing the Delete key on your keyboard. To activate an inactive job, right click on the job name (in black color) and choose Activate.

  • Page 69: Network Node Merge

    Network Node Merge This form view appears when the user is merging two jobs. The source job's Node Addresses must be reassigned if they would clash with those of the target job. The form lists all of the source job's nodes in the left column. If the same Node Address is unused in the target job, it will be automatically assigned in the right column.

  • Page 70: Open Job

    Default user spec'd in user preferences (may be changed). Note: A Comment MUST be entered for the Version history when you create a new Version of a Job. Open Job This dialog, which appears in response to the Open Job command from the Job Menu, allows the user to select a job and job-version in the database and open it in the user interface.

  • Page 71: Panel Information Dialog

    Panel Information Dialog Displays in response to the Panel Information command from the Panel Menu. This dialog displays a summary of panel and the configurator information, with options to view more detail. The information includes: The Product Version • Name and Version of the job currently loaded on the panel. •...

  • Page 72: Paste Special

    An Update button allows the panel time to be corrected/updated from the configurator for those products that support the feature. Paste Special This dialog appears in response to a Paste Special command from the Edit Menu, or right click where you want to paste and select Paste Special from the pop up menu. Used when pasting circuits, conventional adders or entire loops.

  • Page 73: Paste Special

    e.g. Copying Node 1, or Pasting 3 devices to loop 2. Number of copies - specifies the number of copies to make. The paste operation will attempt to make the specified number of copies. If the capacity of the destination is exceeded a message will be displayed to inform the user how many were successfully made.
  • Page 74 Make New Copy - Choose this option to make an unrelated replica of the • source. o Copy I/O Correlations - If this option is checked, the new display item(s) will be correlated to the same circuits and devices as the source. Make Reference Copy - Choose this option to make a reference copy of the •...

  • Page 75: Print Dialog

    Print Dialog To access this dialog, select Print or Print Preview from the File Menu, or click on the print button in the tool bar. Print Range - You can specify the range or scope of the print job using these controls Complete Job - Regardless of what item in the Job Tree you currently have selected, the complete job will be printed.
  • Page 76 Okay – Accepts your choices and sends the document to be printed. Cancel – Closes this dialog without sending anything to be printed. Setup - This button launches the standard Windows Printer Setup dialog. Help – Opens this page in the FleX-Net™ help system.

  • Page 77: Print Setup

    Print Setup Launch the standard Windows Print Setup dialog to specify the printer, paper size and orientation, etc. Restore Database To access this dialog, select Restore Database from the File Menu. Restore database reads a database file and imports every job found there, after first deleting all of the jobs in the current database.

  • Page 78: Security Key Logon

    the form YYYY-MM-DD-Vnn-nn-nn.mdb (the “n”s standing in for the digits in the version number of the current configurator). The backup database could have been produced by an older version of the configuration tool, in which case all necessary conversion is performed. Conversion is sometimes necessary when a new version of the configuration tool is released.
  • Page 79 This dialog will be expanded to include a warning for Security Key expiry date if there are less than 30 days until it will expire. Each Security key has two types of Expiry Date: Mircom Expiry Date and ESD Expiry Date, as can be seen here: Security Key Information The warning message for the Expiry Date contains a 'Remind me later' check-box that will delay any warning message until next day if it is selected and the OK button is pressed.

  • Page 80: Upgrade Firmware

    Upgrade Firmware This dialog appears in response to the Upgrade Firmware command from the Panel Menu. This will open a standard Windows File Browser so that the user may select the firmware he wishes to upgrade to from his hard drive. After User has selected the firmware to upgrade to, the Upgrade Firmware on Panel dialog will open.
  • Page 81 The configurator interrogates the panel to which it is connected and lists all of the CPUs actually present and on-line. The list view shows the CPU Number and Type and other information. Selected CPUs Only - check this box and select the CPUs you wish to upgrade. You can select multiple rows by holding down the Ctrl key and right clicking anywhere in the row.

  • Page 82: User Preferences

    User Preferences To access this dialog, select User Preferences from the File Menu. User Name - used for the Author of all new jobs and job versions • Serial Port - designates which COM port (or USB pseudo COM port) the •...

  • Page 83: Update Panel Time

    Keep Only Latest Versions After Backup - if enabled, only the latest versions • of all jobs will be kept after a successful Backup Database command, all older versions are removed from the current database. Show Advanced Features - if disabled, some of the more advanced features are •...

  • Page 84: Xml Export / Job Details Options Dialog

    Number - The version number. Each time a new version is created, either with the New Version command or by getting a job from the panel or an archive, a new version number is allocated. Date - The date and time the version was created. Changed by - The user who created the version.

  • Page 85: Audio Controller Details

    Audio Controller Details This form view appears in the top, right pane when an Audio Controller item is selected in the Job Tree view. Tag: Enter a description for the audio controller. This will appear in the Job Tree • view.
  • Page 86 supervision). Selecting the wrong charger can affect battery supervision and charging. Microphone present: check this box if there is a microphone installed on this • audio controller. If there are two or more microphones on the job, then one must be flagged as Master and the control enable required option must be checked on every node with a microphone.

  • Page 87: System/Node/Cpu Status

    System/Node/CPU Status This list view appears in the top, right pane when either the Common System Status (available under Job Details), Node & CPU Status Status (available under Node) or Annun Status (available under the LCD Annunciator and Main Display) item is selected in the Job Tree.
  • Page 88 The Scope column specifies the Node and CPU of the status. You must have defined a suitable LED to accept the correlation from the Node or Node/CPU specific status. For a complete list see CPU Status Details. Some columns containing advanced or internal information are normally hidden. They are listed as Visible / No in the following table.
  • Page 89 Name Visible Description Item The database status number. For debugging purposes. The firmware status number. Status Node The Node Number (only applicable for Node and CPU statuses). The CPU Number (only applicable for CPU statuses). Either Common for system wide statuses or the Node name, or Node CPU Scope Yes combination of the status.

  • Page 90: Correlations

    only show unassigned LEDs and Switches as available to be correlated. Correlating the Common System Status to a display item changes the display item's type and assignment. Correlations Most of the primary list views (shown in the top right pane) are used in combination with a correlation view in the bottom right pane.
  • Page 91 Input Circuit Correlations If the currently selected circuit(s) is/are inputs then the correlation view has a tab for Input Zones only. Input Circuits must be combined into input zones before they can be correlated to outputs or LEDs, etc. Input Circuits can only be correlated to Input Zones of a matching type (e.g.

  • Page 92: Interval List View

    Advanced Logic Individual outputs circuits or inputs zones can also be assigned an equation. If only one of these items is selected in the top pane, an Advanced Logic tabbed pane appears. If an advanced logic equation has been composed the text string will appear on the tab. To create a new equation or edit an existing one, use the Edit...
  • Page 93 Interval An internal, allocated number: the single interval range associated with this interval. Start Not used for simple intervals. Year Start Not used for simple intervals. Month Start Not used for simple intervals. Start The hour (0-23) when the interval period is to start. Hour Start The minute (0-59) when the interval period is to start.

  • Page 94: Timer List View

    A 20 character tag to identify the interval. This will appear in the "Symbol Table" when composing equations that reference intervals. The End Hour and End Minute must always be greater than the Start Hour and Start Minute. This means that you will need to set the End Hour and End Minute first or you will get an error message when you try to enter the Start Hour and Start Minute.

  • Page 95: Dialer

    Line 2 can dial a cell phone. If this is the case the auto test can be reduced from daily to monthly. The UDACT can be configured either by using the FX-2000NConfig tool or with the Mircom Dialer Configuration Utility.
  • Page 96 Account 1 Account ID Six digit decimal for the SIA report formats and four digit hexadecimal for Contact ID. Telephone Text Field for telephone number. Report Format Choose from SIA110, SIA300, Contact ID...
  • Page 97 Account 2 Account ID Six digit decimal for the SIA report formats and four digit hexadecimal for Contact ID. Telephone Text Field for telephone number Report Format Choose from SIA110, SIA300, Contact ID Line 1 Dial Using Tone/Pulse Wait Check to wait for dial tone before dialling Line 2 Dial Using Tone/Pulse...
  • Page 98 Attached Fire Alarm Communication Protocol Level 0, Level 1, Level 2 or Level 1G. Only Level 2 (FX2000) is appropriate. Checksum 8 Bit / 16 Bit. For FX2000 16 bit is appropriate. Event Format Ckt No / Loop Addr. Specifies whether the internal Ckt No or a combination of Loop and Address is sent to the monitoring station.
  • Page 99 Line 2 Cellular Test Check this box to indicate that Line 2 dials a cell phone. Use the Spin box to specify the day of the month (1 - 28) for the cell phone test. Auto test at Use this spin box to set the time for a daily test of land lines. Dialer Line Retries Use this Spin Box to specify the number of retries to make (5-10)

  • Page 100: Display Adder

    Display Adder This list view appears in the top, right pane of the user interface when a display adder is selected in the Job Tree. The list displays items (LEDs and Switches) of all the frames on the selected Display Adder. Name Visible Description...
  • Page 101 when Paste Special is used. The linked items can be viewed with the Linked Items dialog. The Frame Number. An adder may contribute several frames to an Frame annunciator. The frame numbers are zero based. The number (zero based) of the first LED of a logical group. For example, an HOA adder has three LEDs per slide switch.
  • Page 102 switch with a higher priority will cause its message to be played, and any lower priority message will cease to play. In a combined fire and Mass Notification System (M.N.S.) installation, choose appropriate priorities. For example, if risk analysis has determined that M.N.S. has priority over fire, assign a higher priority to all M.N.S.

  • Page 103: Equation Summary List View

    Correlatable Switches (being analogous to Input Zones) accept a Tag 2 Conditional second line of 20 characters. Equation Summary List View This list view appears in the top, right pane when the Equation Summary item is selected in the Job Tree view. An equation can be attached to an empty Input Zone, an Output Circuit (not recommended) or a Timer.

  • Page 104: Input / Output Circuit Summary

    The output, zone or timer's tag. Maximum number of equations per CPU is 220. Input / Output Circuit Summary The Job Tree always contains an Input Summary and Output Summary item. Select either of these items to see a list of all of the circuits on the job. On products that support them, this list may include Correlatable Switches.
  • Page 105 The table describes all of the columns in the list view. Name Description Node The Node Name where the device is located. Loop The Loop Number where the device is located. Address The device address of the device. Type The device type (e.g. phone, Signal, Alarm Input, etc.). Node The Node No (does not apply to Timer).

  • Page 106: Input Zones

    The Tag label assigned to the device. Input Zones The list view displays the Input Zones. Input Zones are used to combine multiple input circuits into zones which can then be correlated to signals and other outputs and to display LEDs, etc.
  • Page 107 In a combined fire and Mass Notification System (M.N.S.) installation, choose appropriate priorities. For example, if risk analysis has determined that fire has priority over M.N.S, assign a higher priority to all fire input zones – higher than those of M.N.S. digitized message switches.

  • Page 108: Audio Splitter Zones

    LED Annunciator Summary A FleX-Net™ job's Network Node can have multiple LED Annunciators, but they all share the same programming. There is therefore a maximum of one such item per Network Node in the tree view.

  • Page 109: Loop Controller

    The CPU Address can be changed. A drop down list appears, listing all of the available addresses. The tag can also be edited. LED Annunciators can be added or deleted from this view. If the last instance of the Annunciator is deleted a confirmation message appears. When the last Annunciator is deleted, the item is removed from the job tree.

  • Page 110: Loop Detail

    o AP Start - Enter the starting address of the AP devices on the loop. The address space below this entry will be allocated for CLIP devices and the address space above and including this entry will be allocated for AP devices. Valid AP Start values - 001 to 100.
  • Page 111 The process Type of the Device. Can be edited (combo box). The list of Types shown in the combo box will depend on the Device. Type E.g. Device Relay Output Module can be assigned Relay, Signal or Strobe. Additional refinement of the type. Always has a value of "None" SubType for Input Zones.
  • Page 112 The after hours and night time alarm level 3 sensitivity of the If after hours Sens B Lvl 3 sensor. Displays a combo with sensitivity in appropriate units for specified. the device type. Optional if Lvl2 specified. The text of the tag, in two 20 character fields, representing the Tag (Line 1 two lines displayed on the front panel when an alarm occurs, and Line 2)
  • Page 113 SR - System Reset required - used on Switches used for Fan control • NF - No LED Activation - do not turn ON an addressable device’s LED (and • activate sounder when present) when the device is active. The LED turn ON by default and may only be changed to NF if the Authority Having Jurisdiction allows.

  • Page 114: Main Display / Lcd Annunciator

    Main Display / LCD Annunciator Major Sections Options • o Supervise Printer - check this box to indicate that a printer is permanently attached to this annunciator and its presence should be supervised. If the box is not checked, a printer can be connected at any time (e.g. for debugging) but no trouble will be reported when the printer is removed.
  • Page 115 the Manual Ctrl. switches which have the CR flag set. For details refer to the section Node Control. o Low Power Lamp Test – uses a Lamp test were the LEDs are not as bright and consume less power. o Ring telephone buzzer - check this box if the buzzer on this CPU is required to ring for incoming calls.
  • Page 116 o Use alternate tags - if checked, this display will use the alternate, or secondary tags. This feature can be used to show tags in a different language on designated displays. Alternate tags can be entered on device loop list view.
  • Page 117 o Tag - enter a tag for the annunciator. The tag appears in the tree view. o CPU Address - enter the Remote CPU number for the remote annunciator. The combo box lists the available addresses in the external CPU range. Changing the Man Display Deleting the Main Display.

  • Page 118: Job Details

    There are currently three types of Main Display supported on the FleX-Net™ panel. User can change the type from Main Display drop box. o Another way to change it is from the Main Display submenu item "Base Control/Annun." Right click on the "Base Control/Annun." item and a pop up window will open showing the three types of displays supported, with a check mark beside the currently selected display type.
  • Page 120 Job Info • o Shows details of the job's name, number, creation date and author. The multi-line comments field can be edited and become part of the job's version history. Options • o Two Stage - check to enable two stage. As per UL 864 and UL 2572 only a setting of Single Stage (disabled) is permissible.
  • Page 121 o Silence NAC Audibles Only - If both flags "Silence NAC Audibles Only" and NS are checked the signal silence will silence the horn but the strobe will continue to flash. o Disable Waterflow Retard - this flag indicates there is no extra delay on validating water-flow input activation.
  • Page 122 o System Type - indicates the System Type (compact or large) of the current Job/Version. This field cannot be edited, but for some products the job can be converted between System Types. See Convert Job o Agency - choose between ULI Standard and ULC Standard. Audio •...
  • Page 123 o Node Ctrl Switch: Restricted controls can be used only on the in control node.  Only one node can be in control at a time.  Control is acquired, requested, and passed using node control switches  on each node. o Manual Key Enable: Primary nodes can use restricted controls freely until control is passed to ...
  • Page 124 TRUE while the timer is running. As per UL 864 and UL 2572 only a setting of 0 is permissible. o Powerfail Send Delay - if the only trouble on the system is an AC power failure, transmission of the status through the UDACT can be delayed up to 18 hours.
  • Page 125 Daytime Start and End - specify when daytime begins and ends.  Weekend Start and End - specify when the weekend begins and ends.  Holidays - list the defined holidays.  Modify... - open the Edit Holidays dialog  Reprogram Holiday Trouble - check this box to put the panel into trouble ...

  • Page 126: Job Tree

    Job Tree The Job Tree view represents the job in the form of a tree. At the highest level are items common to the whole system, like Job Details and Custom Timers. Under Job Details, you will find the Network Nodes. Expanding a Node displays all the CPUs on that Node (Base I/O, QLA, Audio, LCD Annunciator), the Main Display, Led...
  • Page 127 Annunciators, and the Node and CPU Status. These can be expanded to reveal their sub- components: individual loops, display adders, etc. When an item in the tree is selected, its details appear in the top, right pane of the user interface.

  • Page 128: Network Node Details

    Network Node Details This form view appears in the top, right pane when a Network Node item is selected in the Job Tree view. Options • o Alternate Ground Fault Detection - If checked, the firmware will use alternate ground fault detection settings to compensate for the capacitance and resistance of long audio cable runs.
  • Page 129 o Two Stage - check to enable two stage. As per UL 864 and UL 2572 only a setting of Single Stage (disabled) is permissible. o Primary Node and Secondary Node - options for the Node Control functionality. Network Setting •...

  • Page 130: Walk Test Areas

    User Name and Password as existing nodes. The defaults are "admin" and "mircom". BACnet • o Enable - If checked, the Node will run a BACnet (Building Automation and Control Networks) Server.

  • Page 131: Drift Compensation

    From the walktest relationship view User can add a new walktest relationship for the selected in the top pane walktest name or delete walktest relationship. OneMan vs. assisted walktest Walktest areas will be exported for all systems (Single or Multi-node) if defined. •...

  • Page 132: Differences Mode / Differences Report

    often it may become possible for an actual fire condition to be compensated out. Agency approval requirements like UL 864 are being established to prevent this from happening. Differences Mode / Differences Report Introduction To access this dialog, select Compare Job Versions from the Job Menu. The configurator has the capability of comparing two jobs.
  • Page 133 from there to the Device Loop in the job tree. A dialog is displayed to inform the user of the progress of difference reporting and to allow the action to be canceled. If you cancel, the display reverts to the primary job, in normal mode. Interpreting the results When the comparisons have all been made, the jobs are presented as one job tree.
  • Page 134 additions. This is because you chose to ignore or exclude them. This icon is only used in the job tree. Items in list views are suppressed completely if you choose not to include items that are identical. If you include items that are identical, then they have no icon at all. This is to avoid clutter and aid readability of the lists.
  • Page 135 If you chose to suppress identical items when you entered differences mode, then any node in the tree that is marked with a green check mark will not be printed. Items whose only difference is in the lower level correlations are also not printed: only the actual correlations. On the printout the symbols - - >...

  • Page 136: Fire Phone Configuration

    Fire Phone Configuration Introduction The configurator allows the user to set up an Audio Controller, conventional phones, addressable phones, remote field phones, master telephone handsets and telephone selectors, and connect them together. There must be at least an Audio Controller, a Telephone Master Controller (QMT-5302N) and Telephone/Page Selector (QZP-5101).
  • Page 137 The following dialog appears. Device: set this to Firephone Module. SubType: the only available option is "None" Address: specify the address for the new device. This defaults to the lowest available address. Number to add: You can specify how many devices to add by changing this value. The configurator will attempt to allocate the devices sequentially, starting with the address you selected.
  • Page 138 Adding Master Telephones Only one Master Telephone can be added to either a RAX or the main display per node. Invoke the Add Display Adder function. This can be done... By pressing the right mouse button, with focus on the tree item representing •...
  • Page 139 The following dialog appears. A Telephone/Page Selector is added to the current Annunciator. It has 24 switches, all of which are initially un-assigned. They can be configured as Zone Sw, Phone Sel, Dig Msg, Page Select, or Node Ctrl. Assigning Selector Switches Any of the 24 switch positions can be edited to be assigned as Phone Sel.
  • Page 140 Adding Switch Corrs to a Phone 1. Navigate to the addressable loop or Audio Controller phone list view containing the telephone and highlight it (one phone at a time) in the device list view. 2. Invoke Add Correlations. 3. The Add Correlations dialog appears and presents a list of all of the available Selector Switches, from all CPUs.
  • Page 141 If you selected more than one Phone to add, or if you press add again, then you will receive the error message “Cannot correlate a Phone Select switch to more than one phone module”. NOTE: The general purpose nature of the Add Correlations dialog means that it cannot prevent multiple selection.

  • Page 142: Get Job

    master telephone correlation is defined. Master telephone correlation shall be removed prior to deletion. Drag & Drop / Copy & Paste A Fire Phone device cannot be copied if it is already correlated to a selector switch. Doing so would break the rule of one switch, one phone. If you attempt to copy such a device (or a loop that contains one) an error message is displayed.
  • Page 143 This command builds the current job (this means taking data from the database and transforming it into the data structures that are understood by the firmware) and prepares a file for every CPU on each selected node. Validation is automatically done as part of the build process. Before the job is sent, the configurator interrogates the panel to discover what version of the product it is running.

  • Page 144: Suite Silence Configuration

    Suite Silence Configuration Introduction The configurator allows the user to configure a combination of System Statuses, timers, input zones and signal zones to satisfy the requirements of the Ontario Building Code with respect to "Suite Silence". The code allows the signals (speakers) in suites other than the suite where the alarm occurred to be automatically silenced.
  • Page 145 Common System Statuses Two Common System Statuses were added to support Suite Silence. New Alarm Active - This status is set to true when a new alarm occurs and • remains true while the New Alarm timer is running. Auto Suite Resound - This status becomes true when the Auto Resound timer •...

  • Page 146: Delete Item

    Delete Item Use this command to delete selected items. You will be prompted to confirm the deletion. The effect of the delete command varies according to what item in the job is selected. By selecting an item in the Job Tree, you can delete an Annunciator, Loop Controller or Display Adder from the job.

  • Page 147: Paste

    Paste Items that have been copied to the clip board can be pasted to another location in the job using this command. See Copy and Paste for full details. Paste Special Items that have been copied to the clip board can be pasted to another location in the job. By choosing Paste Special you can override some of the defaults.

  • Page 148: Add Annunciator

    The new Loop Controller will be added alongside any existing controllers under the currently selected network node. Some models may have a fixed number of addressable and conventional loop controllers, in which case this Insert Menu item will be disabled. Add Annunciator This command will display the Add Annunciator dialog where you can specify the type and number of annunciators to add to your job.

  • Page 149: Add Correlations

    Hardwired Modules: If a conventional, hard-wired loop is selected, the Add Circuit Adders dialog is opened. Addressable Devices: If the currently selected tree item is an addressable device loop this command opens the Add Device dialog allowing you to add one or more devices. Add Amplifier On products that support Audio, select this menu item then the Add Amplifier dialog will appear.

  • Page 150: Open Job

    Open Job This Command launches the Open Job dialog. Use this command to choose a job to open. If a job has more than one version, you can also select the version. Shortcuts Toolbar: Keys: Ctrl-O Merge Job To access this dialog, select Merge Jobs from the Job Menu. This command merges a selected job/version (the source) into the current job (the target).

  • Page 151: New Version

    The source and target jobs may have used the same Node Addresses. The user is prompted to resolve any Node Address conflicts. New Node Addresses for the source job are chosen from the list of available addresses in the target job. Intervals: System intervals such as Holidays, Weekend and Night Time are not copied from the source job.

  • Page 152: Delete Job Version

    Delete Job Version Permanently deletes the currently established Job / Job Version from the database. A confirmation dialog is presented to ensure that this was the user's intent. Shortcuts Keys: Ctrl-D Version History This command will show you a list of the versions of the current job that are in the database. See the Version History dialog.

  • Page 153: Connect

    Connect Use this command to toggle the state of the connection with the fire alarm panel. When a connection is established, other menu and toolbar commands become available. Manage Jobs This Command launches the Manage Jobs dialog, allowing the user to view and delete the jobs stored on the fire panel's file system.

  • Page 154: Build Job

    Build Job This command validates and builds the current job, producing a C file in the Job Build folder. It first shows the Build dialog so that you can choose the product version. You can use this command to produce the C files for older versions of the panel. Link Statistics This command displays statistics for the connection between the configurator and the fire alarm panel.
  • Page 155 Messages are divided into two types: Input and Output. They can be added from the Insert Menu and modified and deleted from the Edit Menu. Alternately, the right click menu presents the same actions. See Add Message The ND (No Display) flag can be set for input message types. When set, no message will be shown on the target CPU's LCD.
  • Page 156 The Add Correlations Dialog therefore adapts to changing conditions. When you select an input message on an annunciator that has no correlated circuits, the Add Correlations dialog shows a list of all existing input circuits, in all four categories. If you now correlate the selected message to an alarm circuit, that circuit is removed from the list of available choices on the Alarm tab and all available circuits are removed from the other tabs: the message is committed to displaying only a group of alarms.

  • Page 157: Security Key Information

    Security Key Information This dialog displays a summary of the Security key information. System Status Details The following table describes the conditions under which each of the system statuses become true: Short Number Device ID Description Name Common Set to TRUE when any of this job's NODEs have **-**-**-ST-000 Alarm their "Node Alarm"...
  • Page 158 Common Set to TRUE when any of this job's NODEs have **-**-**-ST-002 Trouble their "Node Trouble" status equal to TRUE. Common Set to TRUE when any of this job's NODEs have **-**-**-ST-003 Monitor their "Node Monitor" status equal to TRUE. Set to TRUE while any of the Job's nodes have their **-**-**-ST-004 Sys Reset...
  • Page 159 The Total Evacuation alarm status is set to TRUE to indicate that the total general alarm common Total control has been activated or the auto GA timer has **-**-**-ST-011 Evacuation timed out. Once the status is set it will stay active until system reset.
  • Page 160 Silenceable Set to TRUE when silenceable signals are active on **-**-**-ST-019 Opts Active any of the job's Nodes. Set to TRUE when the Auto GA Timer is running. If the system is configured as two stage and the Auto G.A. timer is enabled, it is started when the common alarm sequence is activated in response to Auto GA **-**-**-ST-020...
  • Page 161 Trouble This status is set to TRUE if "Node Trbl Xmit Activ" is **-**-**-ST-025 Xmit Active true on any of the job's Nodes. **-**-**-ST-026 All Call This status is set to TRUE when All Call is active. Page to This status is set to TRUE when Page to Evac is **-**-**-ST-027 Evac active.
  • Page 162 This status is set to TRUE if the conditions which **-**-**-ST-037 Trbl Buzzer would cause the buzzer to sound at the trouble rate are true. This status is set to TRUE if the alarm buzzer is Alm Buzzer currently silenced. The buzzer resounds, and the **-**-**-ST-038 Silence status goes to FALSE if there is a new alarm, if the...
  • Page 163 Set to TRUE if there is an amplifier trouble on any **-**-**-ST-046 Trouble CPU of the job. This status is set to TRUE if there the buzzer silence Telephone switch was used to silence an incoming call buzzer. **-**-**-ST-047 Call In It is set back to FALSE if a new telephone call in is Silenced received or if the alert resound timer expires.

  • Page 164: Node Status Details

    Node Status Details The following table describes the conditions under which each of the node statuses become true: Number Description Short Name Set to TRUE when the system is booted and under normal Node Active circumstances, never set to FALSE. Set to TRUE when all of this Node's CPU have their "AC Power"...
  • Page 165 Node Set to TRUE when any of this NODE's CPUs have their "CPU Subseq Subsequent Alarm" status equal to TRUE. Alarm Node Alarm Set to TRUE when any of this NODE's CPUs have their "Alarm Verif" Verif status equal to TRUE. Node Wflw Set to TRUE when any of this NODE's CPUs have their "Wflw Retard...
  • Page 166 Node Tel Call This status is TRUE when telephone is off hook, or when a user at a Master Telephone presses Call Control. Set to TRUE when the alarm relay on this node is active. The alarm Alm Relay relay is active when there is an alarm on any of this node's Active connected CPUs.

  • Page 167: Cpu Status Details

    CPU Status Details The following table describes the conditions under which each of the CPU statuses become true: Number Description Short Name Set to TRUE when the system is booted and under normal CPU Online circumstances, never set to FALSE CPU Sys Reset Set to TRUE for the duration of the System Reset process Active...
  • Page 168 Set to TRUE when any input zone of process type Alarm on this CPU Evac CPU has reached the evac state. This status will propagate to Node Active Evac Active and from there to the job wide Common Evac Active status.
  • Page 169 Battery Set to TRUE when the battery monitoring circuitry detects a trouble Trouble with batteries on this CPU. Set to TRUE when AC power has been lost on this CPU. Power Fail Note: This is only detected on the main board. Set to TRUE if there is any trouble on this CPU.
  • Page 170 Control This is the inverse of Control Enabled Disabled This status is TRUE when the lamp test switch on this CPU is CPU Lamp Test depressed. It is set to FALSE when the switch is released or when the Lamp Test supervision timer (in case of a stuck switch) expires. CPU Back Light TRUE when the CPU's LCD backlight is off.

  • Page 171: Linked Display Items

    Battery Set to TRUE when the battery charger monitoring circuitry on this Charger CPU detects a trouble. Trouble CPU Batt Similar to Battery Charger trouble, but a indicates a trouble with the Charge Supv supervision circuitry as opposed to the charger itself. Trbl CPU Supply Set to TRUE if the supply voltage to this CPUs power supply is...

  • Page 172: Convert Job

    It contains a list control with the CPU, Adder and Indx of all of the linked items. It can be dismissed by pressing OK. The menu option is not enabled if you highlight items that do not have the asterisk, of if you highlight more than one item with an asterisk. Convert Job This dialog appears in response to the Convert Job command Converted by - The user making the conversion.

  • Page 173: Copy And Paste

    Compact to Large: The Compact build has one addressable loop (Loop 2) on the master CPU, and the remainder, in pairs on Loop Controllers. To accommodate the loop that is moved from the master CPU, an empty loop must be present. One is added if necessary. Loop two is moved to the first addressable controller.
  • Page 174 To override the defaults, press the Shift key before initiating the drag. On dropping the node on the target a Paste Special dialog will appear. You can specify the number of copies to make. You can specify whether I/O correlations and Display Correlations are copied. Copy Display Items Display items can be copied from a list that is currently displayed in the right hand pane, to the same list or another compatible node.
  • Page 175 The same rules apply to Drop as for Paste. There must be sufficient un-assigned LEDs in one block to accommodate the dragged items. The destination must be compatible. E.g. Switches cannot be dragged to an LED annunciator. The default drag & drop operation is to move the items. That is, all attributes of the dragged items are replicated on the new node, with new frame numbers assigned.

  • Page 176: Add Annunciator

    Add Annunciator This dialog is displayed in response to an Add Annunciator command. Type - This control lists the types of Annunciator that can be added to the job. The list will only shows the types that are allowed for your product type. Number to add - Edit this number to add more than one Annunciator to the job.
  • Page 177 Firmware Version • o Select the Major and Minor version to build. You can choose any version in the range from V2.0 up to and including the current version. o Choose the language for the main CPU (for products that support multiple languages).
  • Page 178 CANADA - Main Office U.S.A © Mircom 2021 25 Interchange Way 4575 Witmer Industrial Estates Printed in Canada Subject to change without prior notice Vaughan, ON L4K 5W3 Niagara Falls, NY 14305 Tel: (905) 660-4655 Tel: (905) 660-4655 www.mircom.com (888) 660-4655...

This manual is also suitable for:

Flex-net fx-4000Fx-mns-6000

Table of Contents

Save PDF
