IPS-2424DS Programmable Input Switches Module

The IPS-2424DS Programmable Input Switches Module provides 24 programmable switches,
24 bi-coloured (red/amber) LEDs for fire alarm zone annunciation and 24 amber trouble LEDs

Figure 17 IPS-2424DS Programmable Input Switches Module

BYPASS
BYPASS
BYPASS
BYPASS

Table 6: IPS-2424DS Programmable Input Switches Module Cable Function

Connector
P1 Cable connects to P2 of previous display module.
P1
P2 Cable connects to P1 of next display module
P2
i
Note:
P2
ZONE
ZONE
BYPASS
#5
#1
ZONE
ZONE
BYPASS
#6
#2
ZONE ZONE
BYPASS
#7
#3
ZONE ZONE
BYPASS
#4
#8
P1
The IPS-2424DS module comes with laser printer-compatible slide-in paper
labels for zone labelling.
