4.6

RAX-1048TZDS Zone Display Module

Figure 15 Zone Display Module (RAX-1048TZDS)

P2
P1
Table 4: RAX-1048TZDS Zone Display Module Cable Function
Connector Function
P1 Cable connects to P2 of previous display module.
P1
P2 Cable connects to P1 of next display module
P2
i
The zone display module comes with laser printer-compatible slide-in paper
Note:
labels for zone labelling.
26
