6.2.2 Removing the QAD Amplifier Modules
1. Unscrew the two screws holding the amplifier in place. Do not handle, push or pull any of
the components on the amplifier as this will damage those components.
2. Place the forefinger of one hand on the top section of the amplifier metal front plate and
the forefinger of the other hand on the bottom edge of the amplifier metal front plate.
3. Carefully pull the amplifier forward until the amplifier connector is disconnected from the
backplane connector.
4. Holding the amplifier firmly by the front metal, slide the amplifier forward and completely
remove it from the card cage.
!
Attention: Power should be disconnected before removing and inserting modules
6.3

QCC-6000 Communications Card

The QCC-6000 Card is required for audio system expansion (beyond 1 amplifier cage). It
allows for remote audio cabinet expansion up to 2000 feet (suitable wire gauge is 18 AWG). It
supports up to 9 expansion cabinets on each FleX-Net™ node.
A QCC-6000 Card is required for every audio enclosure if there is more than one audio
enclosure.
Mount the QCC-6000 on the far right side of the audio card cage.
Use the rotary switch SW1 to set the card's address. The card in the main cabinet should be 0.
Set each card consecutively so that there are no gaps.
