Compliance - Mircom FLeXNet FX-MNS-6000 Installation And Operation Manual

DSPL-420DS and DSPL-2440 Displays
standby:
Current Consumption:
alarm:
Fan Damper Display Module (FDX-008W/KI)
24V DC nominal, range of 20 to 39V DC.
standby: 15mA Max.
Current Consumption:
alarm (all LEDs ON): 35mA Max.
Digital Communicator Module (UDACT-300A)
Transmit alarm, supervisory, and trouble to a central monitoring
station.
standby:
Current Consumption:
alarm:

Compliance

System Model: FX-6000MNS-CH
System Type: Local, auxiliary (using PR-300), remote protected premise station (using PR-300 or
UDACT-300A), central station protected premises (using UDACT-300A). Proprietary Sytem (PPU)
and Smoke Control
Type of Service: A, M, WF, SS (with PR-300 or UDACT-300A), PPU
Type of Signalling: Non-coded
Applicable Standards: NFPA 70 and 72, UL-864 R10, ULC S-524, ULC S527-11
107
Programmable Input Switches Module (IPS-2424DS)
25mA and 35mA
Current Consumption:
25mA and 30mA
Programmable Input Switches Module (IPS-4848DS)
Current Consumption:
Adder Annunciator Module RAX-1048TZDS
48 Display Points
Current Consumption: standby: 139 mA
alarm: 1 zone LED active: 26 mA
45 mA
120 mA
standby: 5 mA
alarm (one zone active): 22 mA
standby: 10 mA
alarm (one zone active): 22 mA
2 zone LEDs active: 30 mA
3 zone LEDs active: 35 mA
4 zone LEDs active: 39 mA
48 zone LEDs active: 262 mA
Appendix A: Specifications
