4.5

FOM-2000-UM Fiber Optic Network Module

Figure 14 FOM-2000-UM Fiber Optic Network Module

Bay for optical module
S d i e
One of these modules is required at each panel where fiber optics will be used between them.
The FOM-2000-UM is mounted over the FNC-2000 Network board (over the field wiring
terminals) with two #6 Phillips screws and two Hex spacers.
Table 3:
Connector
P1 cable attaches to P10 of the FNC-2000 Fire Network Controller Module.
P1
JW1 must be on (closed) if an optical module is installed in L1. JW2 must be on (closed)
JW1
if an optical module is installed in L2.
If there is no optical module in L1, remove the jumper from JW1. If there is no optical
module in L2, remove the jumper from JW2.
JW2
25
R X T X
B
JW1
JW2
I2
P1
Connect cable to P10 on the FNC-2000
FOM-2000-UM Fiber Optic Network Module Cable Connection
Bay for optical module
R X T X
S d i e A
I1
Function
