3.1.3 QMP-6101NV Master Paging Microphone and QMT-5302NV Master
Telephone
The QMP-6101NV and QMT-5302NV are mounted on the inner door of the BBX-FXMNS-6000
enclosure Refer to Figure 7
Figure 7
QMP-6101NV
Modules are
mounted from
the backside of
the inner door
using the screws
provided
QMT-5302NV
17
BBX-FXMNS-6000 Inner Door
