External I/O Pin Outs

Table 3-11
Table 3-12
Table 3-13
Table 3-14
3-32
U
RETZTECHNIK LTRASOUND
1
S-VHS IN Video Connector, 4 Pin
Pin No
1
2
3
4
S-VHS OUT Video Connector, 4 Pin
Pin No
1
2
3
4
VGA (Output) Connector, Sub-D 15 Pin
Pin No
1
2
3
4, 9,11,12,15
5, 6, 7, 8, 10
13
14
USB 1, 2 Connectors
Pin No
1
2
3
4
Section 3-6 - System Configuration
Output Signal
SVIDEO IN YG
SVIDEO IN CG
SVIDEO IN Y
SVIDEO IN C
Output Signal
SVIDEO OUT YG
SVIDEO OUT CG
SVIDEO OUT Y
SVIDEO OUT C
Output Signal
VGA OUT1 R
VGA OUT1 G
VGA OUT1 B
N/C
GND
VGA OUT1 HS
VGA OUT1 VS
Output Signal
VCC
- Data
+ Data
GND
V ® 730 S
OLUSON ERVICE
Description
Y (Luma) GND
C (Chroma) GND
Y (Luma) SIGNAL
C (Chroma) SIGNAL
Description
Y (Luma) GND
C (Chroma) GND
Y (Luma) SIGNAL
C (Chroma) SIGNAL
Description
Red
Green
Blue
N/C
GND
H Sync
V Sync
Description
USB Power Supply
USB Data (-)
USB Data (+)
USB Power Ground
