Table 9-14
Item
Part Name
711
KUG5 Remote Cable
712
KUR10 Cable Data SCSI
KVR1 TERM-RS232PC / V730,
713
Y-Cable
KVR2 TERM-RS232PC / V730,
714
Y-Cable
715
KVS2 Cable Serial Interface
716
KVX1 Network Cable
U
RETZTECHNIK
LTRASOUND
1
Miscellaneous Cables
Part Number
KTZ195606
KTZ195473
KTZ195416
KTZ207353
KTZ195717
KTZ212016
Chapter 9 Renewal Parts
Description
VCR -Remote Control Cable
internal Data Cable between SCSI-Module-Connector
and SCSI-Drives (CD-Rom, MO-Drive)
electrical Signal- and Supply-Connection between V730
and User Interface GEU
electrical Signal- and Supply-Connection between
Voluson® 730 and User Interface GEU
(can replace KVR1 cable - KTZ195416)
electrical-Signal-Connection between CPS and
PIC_MG-Slot-CPU
Cable from external rear Panel to the V730-Main-Unit
(internal) rear-Panel 1m
V
® 730 S
OLUSON
ERVICE
Qty
1
1
1
1
1
1
M
ANUAL
FRU
1
1
1
1
1
1
