Chapter 7
Diagnostics/Troubleshooting
Section 7-1
Overview
7-1-1 Purpose of Chapter 7
This section describes how to setup and run the tools and software that help maintain image quality and
system operation. Basic host, system, and board level diagnostics are run whenever power is applied.
Some Service Tools may be run at the application level.
7-1-2 Overview
There may be a time when it would be advantageous to capture trouble images and system data (logs)
for acquisition through remote diagnostics (InSite) or to be sent back to the manufacturer for analysis.
There are different options to acquire this data that would give different results.
Table 7-1
Section
7-1
7-2
7-3
7-4
7-5
7-6
7-7
7-8
U
RETZTECHNIK LTRASOUND
1
Contents in Chapter 7
Overview
Collect Vital System Information
Check Points Voltages
Screen Captures and Logs
How to use the Auto Tester program
Minimum Cable Configuration to Boot
Troubleshooting Trees and Instructions
Error Messages
Chapter 7 Diagnostics/Troubleshooting
Description
V ® 730 S
OLUSON ERVICE
Page Number
7-10
7-20
M
ANUAL
7-1
7-2
7-3
7-4
7-5
7-8
7-1
