Table 3-4
Step
2.
Open front panel (ramp) by removing the screws from the side panels. Lower ramp.
packing
3.
Carefully remove foam packing material, plastic bag from ultrasound unit and the monitor and any other item from the wooden box.
Caution: Two people are needed in the next step due to the weight of the equipment.
4.
Disengage the brakes and slowly move unit down the ramp
Left and Right
panels are
shown removed
for clarity.
Note: Packing crate and material should be stored for future use.
5.
Remove Monitor from its box and mount it on the system.
U
RETZTECHNIK
LTRASOUND
1
Unpacking Procedure
screws
Chapter 3 Installation
Task
Brakes
Brakes
Ramp
Monitor
Mounting
Bracket
Monitor
Connectors
V
® 730 S
OLUSON
ERVICE
screws
ramp
1. Attach Monitor
a) Insert
Press the Monitor
b)
Mounting Bracket
to engage (to hear
a "click").
Check if the moni-
tor is fixed correct.
M
ANUAL
3-5
