4-3-3-3 Monitor Display
Table 4-2
1. Patient Name (family, given, prefix)
2. Hospital Identification
3. Date
4. Time
5. Depth / Frame rate
6. Probe / Application
7. Patient Identification (ID-number)
8. Logo
9. Orientation marker
4-6
U
RETZTECHNIK LTRASOUND
1
Figure 4-6 Monitor Display Tour
Monitor Display Features
Section 4-3 - General Procedure
V
OLUSON
10. Focal zone marker(s)
11. Gray scale wedge
12. Depth scale markers
13. Image Info
14. TGC curve
15. Image Area
16. Status Bar
17. Measurement results
18. Bodymarks
