GE Voluson 730 Service Manual page 79

GE M S - K
EDICAL YSTEMS
D 105844, R
IRECTION EVISION
Table 3-15
Table 3-16
Table 3-17
U
RETZTECHNIK LTRASOUND
1
Network Connector, RJ45 Modular 8 Pin
Pin No
1
2
3
6
Others
R, G, B, SYNC, L-Audio-R (IN/OUT), VHS (IN/OUT) Connectors
Pin No
1 (Center Pin)
2 (Koax Pin)
Footswitch Connector (located at Power Supply Module CPN - rear side)
Pin No
1
2
3
4
Chapter 3 Installation
Output Signal
ETHER TD
ETHER TD
ETHER RD
ETHER RD
NC
Signal
Signal
Signal GND
Input Signal
Signal GND
right switch
left switch
not connected
V ® 730 S
OLUSON ERVICE
Description
Ethernet RD+
Ethernet RD-
Ethernet TD+
Ethernet TD-
Non-connection
Description
Description
normally open
normally open
not connected
M
ANUAL
3-33
