Table 4-12
Step
5
6
7
8
9
10
11
12
13
14
Section 4-6
Peripheral Checks
Check that peripherals work as described below:
Table 4-13
Step
1
Press the FREEZE key.
Press the PRINT A or PRINT B key on the
2
Control Panel.
3
Press the VCR key on the Control Panel twice. VCR starts recording (REC - will be displayed on the screen)
4
Press the VCR key twice again.
5
Press the VCR key on the Control Panel once. The VCR Remote Control menu is displayed on the Touch Panel.
6
Press RECORD on the Touch Panel.
7
Press STOP on the Touch Panel.
8
Press PLAY on the Touch Panel.
9
Press EXIT on the Touch Panel
10
Use the assignable keys on the Touch Panel
4-32
U
RETZTECHNIK LTRASOUND
1
Measurement Setup Checks
Task
General: Check "Store Measurements"
General: Check "Doppler Trace Display Results"
General: Check "Measure Results Display"
OB: Check "Preset Selection"
OB: Check "Pregnancy Weeks"
OB: Check "Ratio Calculations"
OB: Check "GS Measurement Method"
OB: Check "Show Author´s Name at Measure Menu"
Cardiac: Check "2D Circumference and Area Method"
Cardiac: Check "LV Volume Calculation Method"
Peripheral Checks
Task to do
Section 4-6 - Peripheral Checks
V
setting assigned as desired by the customer
settings assigned as desired by the customer
setting assigned as desired by the customer
setting assigned as desired by the customer
setting assigned as desired by the customer
settings assigned as desired by the customer
setting assigned as desired by the customer
setting assigned as desired by the customer
setting assigned as desired by the customer
setting assigned as desired by the customer
Expected Result(s)
Stop image acquisition.
The image displayed on the screen is printed on B&W or Color printer,
depending on the key assignment configuration
VCR stops recording
to start recording
A red dot is displayed in the VCR status area on the Title bar to indicate
that recording has begun
To Stop recording
The video status icon is changed to (Pause)
To start, Play back an examination
to return to the scanning mode
to perform actions on the recorded session, such as stop, pause,
rewind or fast forward.
The video status icon in updated accordingly.
