Section 8-4
Replacement of the Trackball top fixation ring
8-4-1 Manpower
One person, 5 min.
8-4-2 Trackball top fixation ring - Replacement Procedure
1.) Remove the fixation ring by turning it counterclockwise.
rotate clockwise to
mount the fixing ring
2.) Mount the fixation ring by turning it clockwise.
8-8
U
RETZTECHNIK LTRASOUND
1
Figure 8-7 Trackball with top fixation ring
Section 8-4 - Replacement of the Trackball top fixation ring
V ® 730 S
OLUSON ERVICE
rotate counterclockwise
to remove the fixing ring
