For a basic functional check of the system's different modes, following pageswill familiarize you with
image optimization for:
• 2D-Mode (B-Mode)
• M-Mode
• Spectral Doppler Modes
-
-
• Color Doppler Modes
-
-
-
• Volume Modes
-
-
-
-
-
NOTE: Some software may be considered standard depending upon system configuration.
If any Modes or Options are not part of the system configuration, the check can be omitted.
NOTE: Different menus are displayed depending on which Touch Panel Menu and which Mode is selected.
Some function keys only appear on the Touch Panel if they are available for the selected Probe.
4-4-1 2D-Mode Checks
U
RETZTECHNIK LTRASOUND
1
PW - Pulsed Wave Doppler
CW - Continuous Wave Doppler
CFM - Color Flow Mode
PD - Power Doppler
TD - Tissue Doppler
3D
Real Time 4D
Live 3D
Real Time 4D Biopsy
VCI - Volume Contrast Imaging
Figure 4-7 2D Main- and 2D Sub Menu
