External I/O Connection Panel (GES)

If peripherals (e.g. VCR) are connected at the Internal I/O, some connectors on the External I/O may
NOTICE
not be available. Please refer to
1
Table 3-10
Item Connector Name
1 VGA (OUTPUT)
2 R, G, B, H/V, SYNC
3 NETWORK
4 USB-1
5 USB-2
6 AUDIO LEFT OUT
7 AUDIO RIGHT OUT
8 VHS OUT
9 S-VHS OUT
10 AUDIO LEFT IN
11 AUDIO RIGHT IN
12 VHS IN
13 S-VHS IN
U
RETZTECHNIK LTRASOUND
1
Section 5-6 "Internal I/O" on page
2
Figure 3-38 External I/O Panel Connectors
External I/O Connector Description
Table Number
Table 3-13
Table 3-16
Table 3-15
Table 3-14
Table 3-14
Table 3-12
Table 3-11
Chapter 3 Installation
10
3 4 5
6
Description
print out VGA signal with monitor/printer
outputs for color video printer/monitor
DICOM input/output
twisted pair RJ-45 10/100 megabit/s
USB port
USB port
V ® 730 S
OLUSON ERVICE
5-28.
11 12 13
7 8 9
