4-4-12-4 Archiving Images
1.) Insert the archive media.
2.) Press the NETWORK (Sonoview) key on the Control panel.
3.) Format the MOD/CD-RW. To format the media, CD-RW or MOD see
Media" on page
4.) When you click the OPEN button on the upper left side of the screen, a list of all the exams is
displayed see
Open button
5.) Select the exam(s) using the TRACKBALL and the right trackball key SET.
NOTE: The number of all exams of the exam list, the number of currently selected exams, the number
of images and the capacity of selected images are displayed automatically at the right and
upper corner of the exams list.
6.) Click the BACKUP button.
7.) Select on which medium you would like to Backup the files.
8.) After finishing the backup, select whether the selected exam(s) is to be deleted or not.
If you select to delete the exam after finishing the backup, it will be absolutely deleted from the hard
NOTICE
disk of the ultrasound scanner Voluson® 730!
4-30
U
RETZTECHNIK LTRASOUND
1
4-25.
Figure 4-27.
Figure 4-27 Sonoview Screen
Figure 4-28 Backup windows
Section 4-4 - Functional Checks
V ® 730 S
OLUSON ERVICE
Section 4-4-12-1 "Formatting
capacity
of selected
exams
Backup
button
