Section 5-9
External I/O
If peripherals (e.g. VCR) are connected at the Internal I/O, some connectors on the External I/O may
NOTICE
not be available. Please refer to
Table 5-4
Item
1
2
3
4
5
6
7
8
9
10
11
12
13
U
RETZTECHNIK LTRASOUND
1
1
2
Figure 5-17 External I/O Panel Connectors
Section 5-6 "Internal I/O" on page
External I/O Connector Description
Connector Name
VGA (OUTPUT)
R, G, B, H/V SYNC
NETWORK
USB-1
USB-2
AUDIO LEFT OUT
AUDIO RIGHT OUT
VHS OUT
S-VHS OUT
AUDIO LEFT IN
AUDIO RIGHT IN
VHS IN
S-VHS IN
Chapter 5 Components and Functions (Theory)
V
OLUSON
10 11 12 13
3 4 5 6
5-28.
Description
print out VGA signal with monitor/printer
outputs for color video printer/monitor
DICOM input/output
twisted pair RJ-45 10/100 megabit/s
USB port
USB port
® 730 S M
ERVICE ANUAL
7 8 9
