Section 5-2 General Information
MONITOR
GEU
GEM
Major System Components:
• GEF: Main Board Chassis:
-
-
• GEU: Top Console User interface (System I/O with hard keys, Touch screen and EL-Display)
Section 5-7 on page 5-31
• MONITOR:
• GES: External I/O Connection Module
• GEM: Removable Disk drive module (ECG-preamplifier MAN6 - optional)
Section 5-10 on page 5-34
• CPN: Primary Power supply and Isolation transformer for the peripherals
• GW: System mechanical chassis, stand alone trolley to keep all major components
Section 5-12 on page 5-37
U
RETZTECHNIK LTRASOUND
1
Figure 5-2 Major System Components
Section 5-3 on page 5-18
Front-End processor Section 5-4 on page 5-19
Back-End processor Section 5-5 on page 5-24
Section 5-8 on page 5-32
Chapter 5 Components and Functions (Theory)
(cont'd)
GW
without GEU
Section 5-9 on page 5-33
V ® 730 S
OLUSON ERVICE
GES
GEF
CPN
Section 5-11 on page 5-35
M
ANUAL
5-3
