3-5-2

Installing Digital Color Printer Sony UP-D21MD

1.) Power off/Shutdown the system as described in:
2.) Connect the printer as described in:
NOTE: For connection schemes refer to Chapter 20 in the Basic User Manual for Voluson® 730.
Do not connect the USB-cable to the printer!
NOTICE
NOTE: "Mouse functions" can be performed by using the trackball for moving the cursor.
"Normal select" (Click) by pressing the left or right trackball keys and for "opening a context
menu" press the upper trackball key.
3.) Turn ON the printer, then switch ON the power of the system and wait till the system has booted.
NOTE: The power switch of the printer has to be in ON position before starting the system!
3-5-2-1

Install the UP-D21MD printer software/driver

Perform the following steps if this printer was never installed on the Voluson® 730!
4.) Connect the USB cable to the printer and the system. The windows 'Searching for Drivers ...',
'Found new Hardware ...' and finally the following windows appear.
5.) Click the NEXT buttons to start the Hardware Wizard and to locate the driver files.
3-14
U
RETZTECHNIK LTRASOUND
1
Figure 3-15 Found New Hardware Wizard
Section 3-5 - Printer Installation
Section 3-4-4 on page
Section 3-3-1-2 on page 3-6
select "Search for a suitable driver for my
device (recommended)"
Click on "Specify a location"
V ® 730 S
OLUSON ERVICE
3-10.
and reinstall the rear cover plate.
