Disk Drives (GEM)
301
306
Table 9-6
Item Part Name
301
CD/RW-Drive
302
Fan axial 62 x 62 x 14 mm
303
GEM1-1a SCSI Disk Drive Module
304
GEM2 MO-Drive + CR/RW
305
GEM3-3a MO-Drive + CR/RW
306
MO-Drive SCSI 1.3 GB internal
U
RETZTECHNIK LTRASOUND
1
Figure 9-5 Disk Drives (GEM)
Disk Drives (GEM)
Part Number
KTZ207047
KTZ207602
KTZ195474
KTZ154652
KTZ154673
KTZ207050
Chapter 9 Renewal Parts
303
304
305
Description
Standard CD-ROM-Burner internal (no own cabinet)
Fan for Air-Cooling of GEM (SCSI-Drive-Module)
Mechanical Module for SCSI-Drives MO and CD/RW
(used in serial production up to # A06310)
Mechanical Module for SCSI-Drives MO and CD/RW
replaces GEM1-1a
(used in serial production from # A06311 - )
Mechanical Module for SCSI-Drives MO and CD/RW
replaces GEM1-1a and GEM2
(not used in serial production)
Standard Magneto-Optical-Drive SCSI 1.3GB internal
(has no own cabinet)
V ® 730 S
OLUSON ERVICE
302
Qty
1
1
1
1
1
1
M
ANUAL
FRU
1
1
2
2
2
1
