7-7-1 System does not Power On / Boot Up
Is the scanner pluged
Make sure the
Scanner isn't
plugged into
emergency power
(red outlet)
Is there AC at the wall
Is the circuit breaker on
System is on and ready for use
7-10
U
RETZTECHNIK LTRASOUND
1
in?
No
Yes
outlet?
Yes
No
Yes
Switch in ON
No
Position
Fan Noise ?
Yes
Figure 7-12 System does not boot up
Section 7-7 - Troubleshooting Trees and Instructions
+ These three condidtions should be the first items checked if
the scanner doesn't boot up.
+ If all three conditions are present, the scanner should be in
astandby mode with the ON/OFF switch illuminated with amber
color.
+ Follow the flow chart to determine the reason the scanner
doesn't boot up
+ Check if the power switch over the mains plug of the Primary Power
Supply isn't switched off.
+ Check the connections to and from the Power Supply
+ Check the power of the cable which connects the Power Supply with
the GEF module (description Check Points Voltages)
+ If ther is no power and the connections are O.K., replace the Primary
Power Supply
