Take out
AscPos 2 Mold: W1
DlyTime
Speed
0.3 Sec 100
Current Memory
Trvs 0.0 0.0
PFwBw 200.0 200.0
PAscDsc 0.0 0.0
Rot OFF OFF
S지 OFF OFF
Swl
RFwBw
RAscDsc
10%
Main Arm Kick/Return
Main Arm Up/down
Ascent
STEP 3
TRAVERSE
[To setup ascent complete to Traverse 0mm,
Product
FWD/BWD
PFWBW(Kick) 0mm, Ascent 0mm, Chuck Rotation
ASNT/DSNT
OFF]
ROTATION
Press manual so that current number of position
SWIVEL
becomes PFWBW 0.00, PASCDSC 0.00,
Runner
FWD/BWD
Press
ASNT/DSNT
Press
Position
Each axes
Traverse
Rotation
to save
to move to step setting screen.
NEXIA-SY Series User Manual 81
4. Operation
Take out Ascent
0 mm 0 mm
300 mm 200 mm
1250 mm 0 mm
OFF OFF
