4. Operation

4.7.2 Add Motion

(1) Description
This screen allow to add suction, chucking, Spare output or release output that already selected.
(2) Button Function
NO Button
DlyTime:0 .0 Sec
1
2
3
4
5
6
7
8
9
10
Addition, chuck, product grip, nipper, spare 1, spare 2, spare 3 and spare 4 of
action addition indicate status of robot. Setting and canceling by pressing
each relevant button operate robot according to it.
66 NEXIA-SY Series User Manual
AddMot 2 Mold: W1
DlyTime:0 .3 Sec
Product
Set up delay time before performing action.
[Input with numeric keypad]
Turn on/off suction.[Suction On/Suction Off]
Turn on/off chuck.[Chuck On/Chuck Off]
Turn on/off product grip.[Product Grip On/Product Grip Off]
Operate nipper.
Turn on/off spare out 1.
Turn on/off spare out 2.
Turn on/off spare out 3.
Turn on/off spare out 4.
