5. Follow Up

5.9 Ascent Position Setting ( IMM Operate next cycle )

StepSet 2
NO S T E P
1 WaitPos
2 TkPos
3 AscPos
4 RelPos
StepSet 2
NO S T E P
1 WaitPos
2 TkPos
3 AscPos
4 RelPos
130 NEXIA-SY Series User Manual
Take Out Position
Mold: W1
Mold: W1
Ascent Complete Position
STEP 20
Press , display [ no setting ].
Press to close.
STEP 21
Cursor located on AscPos..
Press to setting Ascend Position..
AscPos can be set up only in StepMod ( Step
Modification )
