[Production]
Press Production icons show current information
Target : 8 0 0 0
Current : 8 0 0 0
1 CYCLE: 1 5 .0
TkTime : 5 .0
1DayCount:5 7 6 0
[Stack /Inset]
Displays Stack release and Gripper release information. Press touch screen will show others
Rel
0
C
Array
Grip
0
C
Target : Total Target Number ( Robot will stop after reach this No.)
Current: Current Production Quantity
1 Cycle : 1 Cycle Operation Time ( Sec )
TkTime: Take out cycle time ( Sec)
1DayCount: 1 Day Production Quantity Estimation.
Product/Insert
Empty Spot
1Ly 1R
1Ly 1R
Stack Release: Display stacked products.
Number : Layer of Release Stack
Array display Row and Column of products
stacked.
Insert Grip: Display Insert gripped Position
Array ( Insert ) : Display Row and Column of
Insert Gripped by Robots.
