4.7.3.3 Ascent Position
(1) Description
This is ascent complete position after take out parts, this will allow molding machine to run
next cycle ( Mold will close )
Ascent Position
(2) Button Function
NO
Button
1
DlyTime
00.0 Sec
2
Speed
000 %
3
4
5
Delay time before moving to Ascent Position
[Input with numeric keypad]
Speed necessary for moving to Ascent Position
[input with numeric keypad]
Move to Arc Start Position screen.
Store current value.
Move to Step Setup screen.
AscPos
2
Mold: W1
DlyTime
Speed
0.3 Sec
100
Current Memory
Trvs
0.0
0.0
PFwBw
200.0
200.0
PAscDsc
0.0
0.0
Rot
OFF
OFF
S지
OFF
OFF
Swl
RFwBw
RAscDsc
10%
Description
NEXIA-SY Series User Manual 79
4. Operation
TRAVERSE
Product
FWD/BWD
ASNT/DSNT
ROTATION
SWIVEL
Runner
FWD/BWD
ASNT/DSNT
